LevelOne TURING 28-Port Web Smart Gigabit PoE Switch, 24 PoE Outputs, 4 x SFP

370W

Model GEP-2851EAN 4015867205327

75 specifications

Memory128 MB
Weight3.14 kg
ColourBlack
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity24
10G supportNo

See all specifications

Overview

Memory: 128 MB
Weight: 3.14 kg
Colour: Black
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 24
10G support: No

Brand: LevelOne
Category: Network Switch
Model: GEP-2851
Part number: GEP-2851
EAN / UPC: 4015867205327
Also known as: LevelOne TURING 28-Port Web Smart Gigabit PoE Switch, 24 PoE Outputs, 4 x SFP, 370W

Specifications

75 specifications in 16 groups

Management features

Specification	Value
Switch type	Managed
Quality of Service (QoS) support	Yes
Web-based management	Yes
System event log	Yes

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP module slots quantity	4

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z
10G support	No
Copper ethernet cabling technology	100BASE-TX, 1000BASE-T
Port mirroring	Yes
Broadcast storm control	Yes
Flow control support	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Tagged VLAN, MAC address-based VLAN, Port-based VLAN
Number of VLANs	256

Data transmission

Specification	Value
MAC address table	8000 entries
Switching capacity	56 Gbit/s
Forwarding rate	41.7 Mpps
Store-and-forward	Yes
Jumbo frames support	Yes
Jumbo frames	9216

Security

Specification	Value
DHCP features	DHCP server, DHCP snooping, DHCP client
Access Control List (ACL)	Yes
Authentication type	HWTACACS+, RADIUS
BPDU filtering/protection	Yes
Loop protection	Yes
Root protection	Yes

Protocols

Specification	Value
Management protocols	IPv6, SNMP, RMON
Supported network protocols	IPv4/IPv6

Design

Specification	Value
Rack mounting	Yes
Product colour	Black
Reset button	Yes
LED indicators	Activity, Link, PoE, System
Safety	FCC Part 15 Class A

Performance

Specification	Value
Internal memory	128 MB
Flash memory	32 MB
Buffer size	512 KB
Firmware upgradeable	Yes
Mean time between failures (MTBF)	352063 h

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	15.38 W
Power protection features	Short circuit

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	24
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	370 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 90%
Heat dissipation	1533.62 BTU/h

Weight & dimensions

Specification	Value
Width	442 mm
Depth	211 mm
Height	44 mm
Weight	3.14 kg

Packaging content

Specification	Value
Cables included	AC
Quick start guide	Yes

Packaging data

Specification	Value
Resource CD	Yes
Package width	300 mm
Package depth	520 mm
Package height	90 mm
Package weight	3.85 kg

Certificates

Specification	Value
Certification	CE, RoHS

Logistics data

Specification	Value
Country of origin	Taiwan
Master (outer) case width	482 mm
Master (outer) case length	540 mm
Master (outer) case height	324 mm
Master (outer) case gross weight	19.2 kg
Products per master (outer) case	5 pc(s)
