LevelOne 24-Port Web Smart Gigabit Ethernet PoE Switch, 802.3at PoE+, 24 PoE Outputs, 4 Ports SFP/RJ45 Combo

LevelOne 24-Port Web Smart Gigabit Ethernet PoE Switch, 802.3at PoE+, 24 PoE Outputs, 4 Ports SFP/RJ45 Combo

185W

Model GEP-2450EAN 512706217847

54 specifications

Weight2.4 kg
ColourBlack
Quality of Service (QoS) supportYes
Basic switching RJ-45 Ethernet ports quantity24
10G supportNo
Fiber ethernet cabling technology1000BASE-X

See all specifications

Overview

Weight: 2.4 kg
Colour: Black
Quality of Service (QoS) support: Yes
Basic switching RJ-45 Ethernet ports quantity: 24
10G support: No
Fiber ethernet cabling technology: 1000BASE-X

Brand: LevelOne
Category: Network Switch
Model: GEP-2450
Part number: GEP-2450
EAN / UPC: 512706217847, 846359014868, 4015867164679, 8463590148682
Also known as: LevelOne 24-Port Web Smart Gigabit Ethernet PoE Switch, 802.3at PoE+, 24 PoE Outputs, 4 Ports SFP/RJ45 Combo, 185W

Specifications

54 specifications in 16 groups

Management features

Specification	Value
Quality of Service (QoS) support	Yes

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP module slots quantity	4
Fiber optic connector	SFP

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring	Yes
Full duplex	Yes
Broadcast storm control	Yes
Flow control support	Yes
Link aggregation	Yes
VLAN support	Yes
Virtual LAN features	Tagged VLAN, Port-based VLAN
Number of VLANs	24

Optical fiber

Specification	Value
Fiber ethernet cabling technology	1000BASE-X

Data transmission

Specification	Value
MAC address table	8192 entries
Switching capacity	48 Gbit/s
Number of trunks	12
Number of queues	4
Jumbo frames support	Yes
Jumbo frames	9000

Security

Specification	Value
IGMP snooping	Yes

Multicast features

Specification	Value
Multicast support	Yes

Design

Specification	Value
Rack mounting	Yes
Stackable	No
Product colour	Black
LED indicators	System, Activity, Link, PoE, Speed

Power

Specification	Value
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	250 W
Power protection features	Short circuit

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	24
Total Power over Ethernet (PoE) budget	185 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Width	442 mm
Depth	170 mm
Height	44 mm
Weight	2.4 kg

Packaging content

Specification	Value
Cables included	AC
Manual	Yes
Rack mount kit	Yes

Packaging data

Specification	Value
Resource CD	Yes
Package width	500 mm
Package depth	330 mm
Package height	118 mm
Package weight	4.78 kg

Certificates

Specification	Value
Certification	FCC Part 15 Class A, CE Mark

Logistics data

Specification	Value
Country of origin	Taiwan
