LevelOne 10-Port Gigabit PoE Switch, 8 PoE Outputs, 2 x SFP, 802.3at/af PoE

LevelOne 10-Port Gigabit PoE Switch, 8 PoE Outputs, 2 x SFP, 802.3at/af PoE

65W

Model GEP-1023W65EAN 4015867203323

51 specifications

Weight900 g
ColourBlack
Basic switching RJ-45 Ethernet ports quantity8
10G supportNo
MAC address table8000 entries
Mean time between failures (MTBF)106000 h

See all specifications

Overview

Weight: 900 g
Colour: Black
Basic switching RJ-45 Ethernet ports quantity: 8
10G support: No
MAC address table: 8000 entries
Mean time between failures (MTBF): 106000 h

Brand: LevelOne
Category: Network Switch
Model: GEP-1023W65
Part number: GEP-1023W65
EAN / UPC: 4015867203323
Also known as: LevelOne 10-Port Gigabit PoE Switch, 8 PoE Outputs, 2 x SFP, 802.3at/af PoE, 65W

Specifications

51 specifications in 12 groups

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP module slots quantity	2

Network

Specification	Value
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Cable types supported	Cat3, Cat4, Cat5, Cat5e, Cat6, Cat7
Full duplex	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Flow control support	Yes

Data transmission

Specification	Value
MAC address table	8000 entries
Switching capacity	20 Gbit/s
Jumbo frames support	Yes
Jumbo frames	9000
Packet forwarding rate (1 Gbps)	1488000 pps
Packet forwarding rate (10 Mbps)	14880 pps
Packet forwarding rate (100 Mbps)	148800 pps
Packet buffer memory	1 MB

Design

Specification	Value
Product colour	Black
LED indicators	LAN, PoE, Power, Uplink
Wall mountable	Yes
Regulatory Approvals	EMI: EN55032:2012+AC:2013, EN55022:2010+AC:2011, AS/NZS CISPR 22 Amdt. (2010), EN61000-3-2:2014, EN61000-3-3:2013; EMS: EN55024:2010, IEC61000-4-2:2008, IEC61000-4 3:2006+A1:2007+A2:2010, IEC61000-4-4:2012, IEC61000-4-5:2005, IEC61000 4-6:2013, IEC61000-4-8:2009, IEC61000-4-11:2004

Performance

Specification	Value
Mean time between failures (MTBF)	106000 h

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	8
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	65 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	5 - 90%

Weight & dimensions

Specification	Value
Width	122 mm
Depth	213 mm
Height	45 mm
Weight	900 g

Packaging data

Specification	Value
Package type	Box
Package width	230 mm
Package depth	371 mm
Package height	82 mm
Package weight	1.6 kg

Certificates

Specification	Value
Certification	FCC Class B, CE

Logistics data

Specification	Value
Country of origin	Taiwan
Master (outer) case width	246 mm
Master (outer) case length	525 mm
Harmonized System (HS) code	85176990
Master (outer) case height	392 mm
Master (outer) case gross weight	11 kg
Products per master (outer) case	6 pc(s)
