LevelOne 10-Port Gigabit PoE Switch, 8 PoE Outputs, 2 x SFP, Internal Power Supply, 802.3at/af PoE
120W
Model GEP-1022W120EAN 4015867203316
49 specifications
- Weight1.2 kg
- ColourBlack
- Basic switching RJ-45 Ethernet ports quantity8
- 10G supportNo
- MAC address table8000 entries
- Rack mountingYes
Overview
- Weight
- 1.2 kg
- Colour
- Black
- Basic switching RJ-45 Ethernet ports quantity
- 8
- 10G support
- No
- MAC address table
- 8000 entries
- Rack mounting
- Yes
- Brand
- LevelOne
- Category
- Network Switch
- Model
- GEP-1022W120
- Part number
- GEP-1022W120
- EAN / UPC
- 4015867203316
- Also known as
- LevelOne 10-Port Gigabit PoE Switch, 8 PoE Outputs, 2 x SFP, Internal Power Supply, 802.3at/af PoE, 120W
Specifications
49 specifications in 12 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| SFP module slots quantity | 2 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | No |
| Cable types supported | Cat3, Cat4, Cat5, Cat5e, Cat6, Cat7 |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
| Switching capacity | 20 Gbit/s |
| Jumbo frames support | Yes |
| Packet forwarding rate (1 Gbps) | 1488000 pps |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet forwarding rate (100 Mbps) | 148800 pps |
| Packet buffer memory | 1 MB |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Product colour | Black |
| LED indicators | LAN, PoE, Power, Uplink |
| Regulatory Approvals | EMI:EN55032:2012+AC:2013, EN55022:2010+AC:2011, AS/NZS CISPR 22 Amdt. (2010), EN61000-3-2:2014, EN61000-3-3:2013; EMS: EN55024:2010, IEC61000-4-2:2008, IEC61000-4-3:2006+A1:2007+A2:2010, IEC61000-4-4:2012, IEC61000-4-5:2005, IEC61000-4-6:2013, IEC61000-4-8:2009, IEC61000-4-11:2004 |
Performance
| Specification | Value |
|---|---|
| Mean time between failures (MTBF) | 106000 h |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 120 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 122 mm |
| Depth | 280 mm |
| Height | 45 mm |
| Weight | 1.2 kg |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
| Package width | 230 mm |
| Package depth | 371 mm |
| Package height | 82 mm |
| Package weight | 1.8 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Class B, CE |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
| Master (outer) case width | 246 mm |
| Master (outer) case length | 525 mm |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case height | 392 mm |
| Master (outer) case gross weight | 12 kg |
| Products per master (outer) case | 6 pc(s) |
