LevelOne 8-Port Gigabit PoE Switch, 802.3at/af PoE, 4 PoE Outputs

LevelOne 8-Port Gigabit PoE Switch, 802.3at/af PoE, 4 PoE Outputs

90W

Model GEP-0812W90EAN 4015867199756

62 specifications

Weight1.5 kg
ColourGrey
Basic switching RJ-45 Ethernet ports quantity8
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
MAC address table8000 entries
DHCP featuresDHCP snooping, DHCP relay

See all specifications

Overview

Weight: 1.5 kg
Colour: Grey
Basic switching RJ-45 Ethernet ports quantity: 8
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
MAC address table: 8000 entries
DHCP features: DHCP snooping, DHCP relay

Brand: LevelOne
Category: Network Switch
Model: GEP-0812W90
Part number: GEP-0812W90
EAN / UPC: 4015867199756
Also known as: LevelOne 8-Port Gigabit PoE Switch, 802.3at/af PoE, 4 PoE Outputs, 90W

Specifications

62 specifications in 14 groups

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	8
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0

Network

Specification	Value
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Full duplex	Yes
Auto-negotiation	Yes
Flow control support	Yes
MAC address auto-aging supported	Yes
MAC address auto-learning supported	Yes

Data transmission

Specification	Value
MAC address table	8000 entries
Switching capacity	16 Gbit/s
Store-and-forward	Yes
Static route	Yes
Jumbo frames support	Yes
Jumbo frames	9000
Packet forwarding rate (1 Gbps)	1488000 pps
Packet forwarding rate (10 Mbps)	14880 pps
Packet forwarding rate (100 Mbps)	148000 pps

Security

Specification	Value
DHCP features	DHCP snooping, DHCP relay
SSH/SSL support	Yes

Design

Specification	Value
Rack mounting	Yes
Product colour	Grey
Housing material	Metal
LED indicators	Activity, PoE, Power

Performance

Specification	Value
Buffer size	128 KB
sFlow	Yes

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	2 A
Power consumption (typical)	90 W
Power protection features	Over current, Short circuit

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	4
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	85 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Width	280 mm
Depth	125.5 mm
Height	44 mm
Weight	1.5 kg

Packaging content

Specification	Value
Cables included	AC
Quick start guide	Yes
Rack mount kit	Yes

Packaging data

Specification	Value
Package type	Box
Package width	235 mm
Package depth	83 mm
Package height	377 mm
Package weight	1.7 kg

Certificates

Specification	Value
Certification	FCC, CE, RoHS

Logistics data

Specification	Value
Country of origin	Taiwan
Master (outer) case width	246 mm
Master (outer) case length	392 mm
Harmonized System (HS) code	85176990
Master (outer) case height	525 mm
Master (outer) case gross weight	10.2 kg
Products per master (outer) case	6 pc(s)
