LevelOne 16-Port Web Smart Fast Ethernet PoE Switch, 802.3af PoE

LevelOne 16-Port Web Smart Fast Ethernet PoE Switch, 802.3af PoE

123.2W, 8 PoE Outputs

Model FSW-1671EAN 878742006808

47 specifications
  • ColourBlack
  • Quality of Service (QoS) supportYes
  • Basic switching RJ-45 Ethernet ports quantity16
  • 10G supportNo
  • MAC address table4096 entries
  • Buffer size192 KB
See all specifications

Overview

Colour
Black
Quality of Service (QoS) support
Yes
Basic switching RJ-45 Ethernet ports quantity
16
10G support
No
MAC address table
4096 entries
Buffer size
192 KB
Brand
LevelOne
Model
FSW-1671
Part number
FSW-1671
EAN / UPC
878742006808, 4015867148884, 5050914833664
Also known as
LevelOne 16-Port Web Smart Fast Ethernet PoE Switch, 802.3af PoE, 123.2W, 8 PoE Outputs

Specifications

47 specifications in 15 groups

Management features

Quality of Service (QoS) supportYes
Web-based managementYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity16
Basic switching RJ-45 Ethernet ports typeFast Ethernet (10/100)
Installed SFP modules quantity0
Installed SFP+ modules quantity0

Network

Networking standardsIEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
10G supportNo
Copper ethernet cabling technology10BASE-T, 100BASE-TX
Port mirroringYes
Full duplexYes
Auto MDI/MDI-XYes
Auto-negotiationYes
Broadcast storm controlYes
VLAN supportYes
Virtual LAN featuresTagged VLAN, Port-based VLAN

Data transmission

MAC address table4096 entries
Switching capacity3.2 Gbit/s
Store-and-forwardYes
Number of trunks6
Number of queues4

Security

IGMP snoopingYes

Multicast features

Multicast supportYes

Design

Rack mountingYes
StackableNo
Product colourBlack
LED indicatorsActivity, Link, Power
On/off switchYes

Performance

Buffer size192 KB
Firmware upgradeableYes
Mean time between failures (MTBF)179657.9743 h

Power

AC input voltage90 - 260 V
AC input frequency50 - 60 Hz
Power consumption (typical)130.7 W
Power protection featuresOver current, Over power

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity8
Power over Ethernet (PoE) power per port15.4 W

Operational conditions

Operating temperature (T-T)0 - 60 °C
Storage temperature (T-T)-20 - 90 °C
Operating relative humidity (H-H)10 - 90%

Packaging content

Cables includedAC
ManualYes
Rack mount kitYes

Packaging data

Resource CDYes

Certificates

CertificationCE FCC Part 15 Class A

Logistics data

Country of originTaiwan
