50-Port Fast Ethernet Switch, 2 x Gigabit SFP/RJ45 Combo
Model FGU-5021EAN 4015867198407
55 specifications
- Memory16 MB
- Weight2.7 kg
- ColourGrey
- Basic switching RJ-45 Ethernet ports quantity50
- 10G supportNo
- Fiber ethernet cabling technology100BASE-X, 1000BASE-X
Overview
- Memory
- 16 MB
- Weight
- 2.7 kg
- Colour
- Grey
- Basic switching RJ-45 Ethernet ports quantity
- 50
- 10G support
- No
- Fiber ethernet cabling technology
- 100BASE-X, 1000BASE-X
- Brand
- LevelOne
- Category
- Network Switch
- Model
- FGU-5021
- Part number
- FGU-5021
- EAN / UPC
- 4015867198407, 4015867198414
- Also known as
- LevelOne 50-Port Fast Ethernet Switch, 2 x Gigabit SFP/RJ45 Combo
Specifications
55 specifications in 14 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 50 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Fast Ethernet (copper) ports quantity | 48 |
| Gigabit Ethernet (copper) ports quantity | 2 |
| Combo SFP ports quantity | 2 |
| Fiber optic connector | SFP |
| Console port | RJ-45 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
| 10G support | No |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T, 1000BASE-TX |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| MAC address auto-aging supported | Yes |
| MAC address auto-learning supported | Yes |
Optical fiber
| Specification | Value |
|---|---|
| Fiber ethernet cabling technology | 100BASE-X, 1000BASE-X |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
| Switching capacity | 13.6 Gbit/s |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Packet buffer memory | 4 MB |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Product colour | Grey |
| Housing material | Metal |
| LED indicators | Activity, Link, Power |
Performance
| Specification | Value |
|---|---|
| Internal memory | 16 MB |
Power
| Specification | Value |
|---|---|
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 28.6 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 44 mm |
| Depth | 230 mm |
| Height | 440 mm |
| Weight | 2.7 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| Quick start guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package type | Gift box |
| Package width | 375 mm |
| Package depth | 100 mm |
| Package height | 510 mm |
| Package weight | 2.82 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | CE/FCC |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
| Master (outer) case width | 520 mm |
| Master (outer) case length | 395 mm |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case height | 535 mm |
| Master (outer) case gross weight | 13.8 kg |
| Products per master (outer) case | 5 pc(s) |
