LevelOne 34-Port Fast Ethernet PoE Switch, 802.3at/af PoE, 32 PoE Outputs, 2 x Gigabit RJ45

34-Port Fast Ethernet PoE Switch, 802.3at/af PoE, 32 PoE Outputs, 2 x Gigabit RJ45

380W

Model FGP-3400W380EAN 4015867203255

57 specifications

Weight2.8 kg
ColourBlack
Switch typeUnmanaged
Basic switching RJ-45 Ethernet ports quantity32
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
MAC address table32000 entries

See all specifications

Overview

Weight: 2.8 kg
Colour: Black
Switch type: Unmanaged
Basic switching RJ-45 Ethernet ports quantity: 32
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
MAC address table: 32000 entries

Brand: LevelOne
Category: Network Switch
Model: FGP-3400W380
Part number: FGP-3400W380
EAN / UPC: 4015867203255
Also known as: LevelOne 34-Port Fast Ethernet PoE Switch, 802.3at/af PoE, 32 PoE Outputs, 2 x Gigabit RJ45, 380W

Specifications

57 specifications in 14 groups

Management features

Specification	Value
Switch type	Unmanaged

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	32
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Fast Ethernet (copper) ports quantity	32
Gigabit Ethernet (copper) ports quantity	2
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0

Network

Specification	Value
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported	Cat3, Cat4, Cat5, Cat5e, Cat6, Cat7
Full duplex	Yes
Flow control support	Yes

Data transmission

Specification	Value
MAC address table	32000 entries
Switching capacity	10.4 Gbit/s
Jumbo frames support	Yes
Jumbo frames	16000
Packet forwarding rate (1 Gbps)	1488000 pps
Packet forwarding rate (10 Mbps)	14880 pps
Packet forwarding rate (100 Mbps)	148800 pps
Packet buffer memory	8 MB

Design

Specification	Value
Rack mounting	Yes
Product colour	Black
LED indicators	LAN, PoE, Power, Uplink
On/off switch	Yes
Regulatory Approvals	EMI:EN55032:2012+AC:2013, EN55022:2010+AC:2011, AS/NZS CISPR 22 Amdt. (2010), EN61000-3-2:2014, EN61000-3-3:2013;EMS: EN55024:2010, IEC61000-4-2:2008, IEC61000-4 3:2006+A1:2007+A2:2010, IEC61000-4-4:2012, IEC61000-4-5:2005, IEC61000-4-6:2013, IEC61000-4-8:2009, IEC61000-4-11:2004

Performance

Specification	Value
Mean time between failures (MTBF)	74000 h

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	32
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	380 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Width	195 mm
Depth	480 mm
Height	45 mm
Weight	2.8 kg

Packaging content

Specification	Value
Cables included	AC
Quick start guide	Yes
Rack mount kit	Yes

Packaging data

Specification	Value
Package type	Box
Rubber feet	Yes
Package width	255 mm
Package depth	534 mm
Package height	95 mm
Package weight	3.3 kg

Certificates

Specification	Value
Certification	FCC Class A, CE

Logistics data

Specification	Value
Country of origin	Taiwan
Master (outer) case width	510 mm
Master (outer) case length	555 mm
Harmonized System (HS) code	85176990
Master (outer) case height	280 mm
Master (outer) case gross weight	17.8 kg
Products per master (outer) case	5 pc(s)
