LevelOne 16-Port Fast Ethernet PoE Switch, 802.3at/af PoE

LevelOne 16-Port Fast Ethernet PoE Switch, 802.3at/af PoE

500W

Model FEP-1612EAN 846359018972

46 specifications
  • Weight2.85 kg
  • ColourGrey
  • Switch typeUnmanaged
  • Basic switching RJ-45 Ethernet ports quantity16
  • 10G supportNo
  • MAC address table4096 entries
See all specifications

Overview

Weight
2.85 kg
Colour
Grey
Switch type
Unmanaged
Basic switching RJ-45 Ethernet ports quantity
16
10G support
No
MAC address table
4096 entries
Brand
LevelOne
Model
FEP-1612
Part number
FEP-1612
EAN / UPC
846359018972, 4015867170137, 5050914833367, 8463590189722
Also known as
LevelOne 16-Port Fast Ethernet PoE Switch, 802.3at/af PoE, 500W

Specifications

46 specifications in 14 groups

Management features

Switch typeUnmanaged

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity16
Basic switching RJ-45 Ethernet ports typeFast Ethernet (10/100)
Installed SFP modules quantity0
Installed SFP+ modules quantity0

Network

Networking standardsIEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
10G supportNo
Copper ethernet cabling technology10BASE-T, 100BASE-TX
Cable types supportedCat5
Full duplexYes
Auto MDI/MDI-XYes
Auto-negotiationYes

Data transmission

MAC address table4096 entries
Switching capacity3.2 Gbit/s
Store-and-forwardYes
Packet forwarding rate (10 Mbps)14880 pps
Packet forwarding rate (100 Mbps)148000 pps

Design

Rack mountingYes
StackableNo
Product colourGrey
LED indicatorsActivity, LAN, PoE, Power

Performance

Buffer size160 KB

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current5 A
Power consumption (typical)500 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes
Power over Ethernet plus (PoE+) ports quantity16
Total Power over Ethernet (PoE) budget480 W

Operational conditions

Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)10 - 90%

Weight & dimensions

Width200 mm
Depth480 mm
Height44 mm
Weight2.85 kg

Packaging content

Cables includedAC
Quick start guideYes

Packaging data

Package width260 mm
Package depth535 mm
Package height90 mm
Package weight3.7 kg

Certificates

CertificationFCC, CE

Logistics data

Country of originTaiwan
Harmonized System (HS) code85176990
