LevelOne 8-Port Fast Ethernet PoE Switch, 802.3at/af PoE

LevelOne 8-Port Fast Ethernet PoE Switch, 802.3at/af PoE

250W

Model FEP-0811W250EAN 4015867199800

56 specifications
  • Weight16 kg
  • ColourGrey
  • Basic switching RJ-45 Ethernet ports quantity8
  • 10G supportNo
  • MAC address table1000 entries
  • Rack mountingYes
See all specifications

Overview

Weight
16 kg
Colour
Grey
Basic switching RJ-45 Ethernet ports quantity
8
10G support
No
MAC address table
1000 entries
Rack mounting
Yes
Brand
LevelOne
Model
FEP-0811W250
Part number
FEP-0811W250
EAN / UPC
4015867199800
Also known as
LevelOne 8-Port Fast Ethernet PoE Switch, 802.3at/af PoE, 250W

Specifications

56 specifications in 13 groups

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeFast Ethernet (10/100)
Installed SFP modules quantity0
Installed SFP+ modules quantity0

Network

Networking standardsIEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
10G supportNo
Copper ethernet cabling technology10BASE-T, 100BASE-TX
Cable types supportedCat3, Cat4, Cat5
Full duplexYes
Auto MDI/MDI-XYes
Auto-negotiationYes
Flow control supportYes

Data transmission

MAC address table1000 entries
Switching capacity1.6 Gbit/s
Store-and-forwardYes
Packet forwarding rate (10 Mbps)14880 pps
Packet forwarding rate (100 Mbps)148000 pps

Design

Rack mountingYes
Product colourGrey
Housing materialMetal
LED indicatorsActivity, PoE, Power
On/off switchYes

Performance

Buffer size64 KB

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current2 A
Power consumption (typical)250 W
Power protection featuresOver current

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes
Power over Ethernet plus (PoE+) ports quantity8
Power over Ethernet (PoE) power per port30 W
Total Power over Ethernet (PoE) budget245 W

Operational conditions

Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-40 - 75 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)10 - 90%

Weight & dimensions

Width182 mm
Depth278 mm
Height44 mm
Weight16 kg

Packaging content

Cables includedAC
Quick start guideYes
Rack mount kitYes

Packaging data

Package typeBox
Package width230 mm
Package depth371 mm
Package height82 mm
Package weight18.5 kg

Certificates

CertificationFCC, CE, RoHS

Logistics data

Country of originTaiwan
Master (outer) case width250 mm
Master (outer) case length520 mm
Harmonized System (HS) code85176990
Master (outer) case height400 mm
Master (outer) case gross weight2.1 kg
Products per master (outer) case6 pc(s)
