LevelOne 3-Port Fast Ethernet PoE Switch, 2 PoE Outputs

LevelOne 3-Port Fast Ethernet PoE Switch, 2 PoE Outputs

36W

Model FEP-0311W36Part no. FEP-0311W24EAN 4015867203217

52 specifications

Weight200 g
ColourBlack
Basic switching RJ-45 Ethernet ports quantity3
10G supportNo
MAC address table4000 entries
Buffer size384 KB

See all specifications

Overview

Weight: 200 g
Colour: Black
Basic switching RJ-45 Ethernet ports quantity: 3
10G support: No
MAC address table: 4000 entries
Buffer size: 384 KB

Brand: LevelOne
Category: Network Switch
Model: FEP-0311W36
Part number: FEP-0311W24
EAN / UPC: 4015867203217
Also known as: LevelOne 3-Port Fast Ethernet PoE Switch, 2 PoE Outputs, 36W

Specifications

52 specifications in 13 groups

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	3
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0

Network

Specification	Value
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
10G support	No
Cable types supported	Cat3, Cat4, Cat5
Full duplex	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Flow control support	Yes

Data transmission

Specification	Value
MAC address table	4000 entries
Switching capacity	0.6 Gbit/s
Jumbo frames support	Yes
Jumbo frames	2000
Packet forwarding rate (10 Mbps)	14880 pps
Packet forwarding rate (100 Mbps)	148800 pps

Design

Specification	Value
Product colour	Black
LED indicators	LAN, PoE, Power, Uplink
Regulatory Approvals	EMI: EN55022:2010 Class B, AS/NZS CISPR 22 Amdt. (2010), EN61000-3-2:2014, EN61000-3-3:2013; EMS: EN55024:2010, IEC61000-4-2:2008, IEC61000-4-3:2006+A1:2007+A2:2010, IEC61000-4-4:2012, IEC61000-4-5:2014, IEC61000-4-6:2013, IEC61000-4-8:2009, IEC61000-4-11:2004

Performance

Specification	Value
Buffer size	384 KB
Mean time between failures (MTBF)	190000 h

Power

Specification	Value
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power protection features	Over current, Over voltage, Overheating

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	2
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	36 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Width	62 mm
Depth	90 mm
Height	27 mm
Weight	200 g

Packaging content

Specification	Value
Manual	Yes

Packaging data

Specification	Value
AC adapter included	Yes
Package type	Box
Package width	146 mm
Package depth	222 mm
Package height	78 mm
Package weight	800 g

Certificates

Specification	Value
Certification	FCC Class B, CE

Logistics data

Specification	Value
Country of origin	Taiwan
Master (outer) case width	422 mm
Master (outer) case length	310 mm
Master (outer) case height	252 mm
Master (outer) case gross weight	9 kg
Products per master (outer) case	10 pc(s)
