LevelOne 12G + 2SFP L2 SNMP POE Stacking Switch
Model 12G + 2SFP L2 SNMP POE Stacking SwitchPart no. GSW-1291
32 specifications
- Speed1 Gbit/s
- ConnectivityWired
- ColourSilver
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity12
- Copper ethernet cabling technology1000Base-T, 100Base-TX, 10Base-T
Overview
- Speed
- 1 Gbit/s
- Connectivity
- Wired
- Colour
- Silver
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 12
- Copper ethernet cabling technology
- 1000Base-T, 100Base-TX, 10Base-T
- Brand
- LevelOne
- Category
- Network Switch
- Model
- 12G + 2SFP L2 SNMP POE Stacking Switch
- Part number
- GSW-1291
- Also known as
- LevelOne 12G + 2SFP L2 SNMP POE Stacking Switch Managed Power over Ethernet (PoE) Silver
Specifications
32 specifications in 11 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 12 |
| SFP module slots quantity | 2 |
| SFP/SFP+ slots quantity | 2 |
| Console port | RS-232 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1D, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3z |
| Copper ethernet cabling technology | 1000Base-T, 100Base-TX, 10Base-T |
| IP routing | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8192 entries |
| Supported data transfer rates | 10/100/1000 Mbps |
| Store-and-forward | Yes |
| Maximum data transfer rate | 1 Gbit/s |
| Packet buffer memory | 0.2 MB |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Design
| Specification | Value |
|---|---|
| Stackable | Yes |
| Product colour | Silver |
| Number of fans | 1 fan(s) |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 15 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 442 x 209 x 44 mm |
| Connectivity technology | Wired |
| Power requirements | 100-240VAC, 50/60Hz |
| Size (imperial) | 48.3 cm (19") |
| Wi-Fi | No |
| Connectivity LEDs | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 90% |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Class A, CE |
