Lenovo NE2572 Managed L2/L3 1U Black
Model NE2572Part no. 7159E1XEAN 889488425488
52 specifications
- Noise90 dB
- Type1U
- Weight11.4 kg
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity0
Overview
- Noise
- 90 dB
- Type
- 1U
- Weight
- 11.4 kg
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 0
- Brand
- Lenovo
- Category
- Network Switch
- Model
- NE2572
- Part number
- 7159E1X
- EAN / UPC
- 889488425488
- Also known as
- Lenovo NE2572 Managed L2/L3 1U Black
Specifications
52 specifications in 15 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | No |
| SFP+ module slots quantity | 48 |
| QSFP+ module slots quantity | 6 |
| Console port | RJ-45 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3ba, IEEE 802.3bm, IEEE 802.3cc, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
| Number of VLANs | 4095 |
Optical fiber
| Specification | Value |
|---|---|
| Fiber ethernet cabling technology | 10GBASE-ER, 10GBASE-LR, 10GBASE-SR, 25GBASE-LR, 25GBASE-SR, 40GBASE-LR4, 40GBASE-SR4, 100GBASE-LR4, 100GBASE-SR4 |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 104000 entries |
| Throughput | 3600000 Mpps |
| Static route | Yes |
| Number of static routes | 256 |
| Packet buffer memory | 22 MB |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP relay, DHCP snooping |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| Password protection | Yes |
| Security algorithms | SSH |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNMP V1, V2, V3 |
| Routing protocols | BGP4, OSPF |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
| Airflow direction | Back-to-front airflow |
| Number of fans | 6 fan(s) |
Performance
| Specification | Value |
|---|---|
| Noise level | 90 dB |
| Mean time between failures (MTBF) | 242685 h |
Power
| Specification | Value |
|---|---|
| Power supply included | Yes |
| Redundant power supply (RPS) support | Yes |
| Number of power supply units | 2 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 213 W |
| Power consumption (max) | 289 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 727 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 441 mm |
| Depth | 487 mm |
| Height | 44 mm |
| Weight | 11.4 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | ROHS, UL/IEC 60950-1, TUV-GS, IEC-60950-1, NOM-019 , KN22, KN24, VCCI, IEC 60950-1, CISPR 22, ICES-003, IEC60950-1 |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
