Lenovo G8052 Managed L2/L3 Gigabit Ethernet (10/100/1000) 1U Black

Lenovo G8052 Managed L2/L3 Gigabit Ethernet (10/100/1000) 1U Black

Model G8052Part no. 7159G52EAN 889488005925

53 specifications
  • Noise65 dB
  • Type1U
  • Weight10.5 kg
  • ColourBlack
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity48
See all specifications

Overview

Noise
65 dB
Type
1U
Weight
10.5 kg
Colour
Black
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
48
Brand
Lenovo
Model
G8052
Part number
7159G52
EAN / UPC
889488005925
Also known as
Lenovo G8052 Managed L2/L3 Gigabit Ethernet (10/100/1000) 1U Black

Specifications

53 specifications in 15 groups

Management features

Switch typeManaged
Switch layerL2/L3
Quality of Service (QoS) supportYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity48
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
SFP+ module slots quantity4
Console portUSB
USB 2.0 ports quantity1

Network

Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportYes
Port mirroringYes
Link aggregationYes
VLAN supportYes
Virtual LAN featuresTagged VLAN
Number of VLANs4095

Optical fiber

Fiber ethernet cabling technology10GBASE-ER, 10GBASE-LR, 10GBASE-SR

Data transmission

MAC address table32000 entries
Throughput176000 Mpps
Static routeYes
Number of static routes128
Packet buffer memory4 MB

Security

DHCP featuresDHCP relay
Access Control List (ACL)Yes
IGMP snoopingYes
Password protectionYes
Security algorithmsSSH

Multicast features

Multicast supportYes

Protocols

Management protocolsSNMP V1, V3
Routing protocolsBGP, OSPF, RIP

Design

Rack mountingYes
Form factor1U
Product colourBlack
Airflow directionBack-to-front airflow
Number of fans3 fan(s)
Electromagnetic compatibilityFCC 47CFR Part 15 Class A, EN 55022 Class A, ICES-003 Class A, VCCI Class A, AS/NZS CISPR 22 Class A, CISPR 22 Class A, EN 55024, EN 300386, CE

Performance

Noise level65 dB
Mean time between failures (MTBF)190860 h

Power

Power supply includedYes
Redundant power supply (RPS) supportYes
Number of power supply units2
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)130 W
Power consumption (max)200 W

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90%
Heat dissipation444 BTU/h

Weight & dimensions

Width439 mm
Depth445 mm
Height44 mm
Weight10.5 kg

Certificates

CertificationROHS, UL60950-1, CAN/CSA 22.2 No.60950-1, TUV/GS to EN 60950-1, IEC60950-1, GB17625.1-2012, CNS 14336-1, 2010

Logistics data

Harmonized System (HS) code85176990
