Intellinet 16-Port Fast Ethernet PoE+ Switch, 8 x PoE IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE) ports, 8 x Standard RJ45 Ports, Endspan

Intellinet 16-Port Fast Ethernet PoE+ Switch, 8 x PoE IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE) ports, 8 x Standard RJ45 Ports, Endspan

19" Rackmount (Eur

Model 560771EAN 7666235607716

28 specifications
  • Type1U
  • Weight3.65 kg
  • ColourBlack
  • Basic switching RJ-45 Ethernet ports quantity16
  • Cable types supportedCat3, Cat4, Cat5
  • Forwarding rate0.1488 Mpps
See all specifications

Overview

Type
1U
Weight
3.65 kg
Colour
Black
Basic switching RJ-45 Ethernet ports quantity
16
Cable types supported
Cat3, Cat4, Cat5
Forwarding rate
0.1488 Mpps
Brand
Intellinet
Model
560771
Part number
560771
EAN / UPC
7666235607716, 044111329407, 132018543924, 163121507046 +9 more
Also known as
Intellinet 16-Port Fast Ethernet PoE+ Switch, 8 x PoE IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE) ports, 8 x Standard RJ45 Ports, Endspan, 19" Rackmount (Eur

Specifications

28 specifications in 11 groups

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity16
Basic switching RJ-45 Ethernet ports typeFast Ethernet (10/100)

Network

Networking standardsIEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Cable types supportedCat3, Cat4, Cat5
Full duplexYes
Flow control supportYes

Data transmission

Forwarding rate0.1488 Mpps

Design

Rack mountingYes
Form factor1U
Product colourBlack
Housing materialMetal
LED indicatorsYes

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)65 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 90 °C
Operating relative humidity (H-H)10 - 90%

Weight & dimensions

Width440 mm
Depth220 mm
Height44 mm
Weight3.65 kg

Packaging content

Cables includedAC
ManualYes
Rack mount kitYes

Certificates

CertificationFCC Class A, CE

Logistics data

Harmonized System (HS) code85176990
