Intellinet 8-Port Fast Ethernet PoE+ Switch, 8 x PoE ports, IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE), Endspan, Desktop, Box

Intellinet 8-Port Fast Ethernet PoE+ Switch, 8 x PoE ports, IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE), Endspan, Desktop, Box

Model 560764EAN 946296444176

31 specifications
  • Weight1.5 kg
  • ColourBlack
  • Basic switching RJ-45 Ethernet ports quantity8
  • 10G supportNo
  • MAC address table2048 entries
  • AC input voltage100 - 240 V
See all specifications

Overview

Weight
1.5 kg
Colour
Black
Basic switching RJ-45 Ethernet ports quantity
8
10G support
No
MAC address table
2048 entries
AC input voltage
100 - 240 V
Brand
Intellinet
Model
560764
Part number
560764
EAN / UPC
946296444176, 011411364636, 115971124218, 132017733876 +13 more
Also known as
Intellinet 8-Port Fast Ethernet PoE+ Switch, 8 x PoE ports, IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE), Endspan, Desktop, Box

Specifications

31 specifications in 11 groups

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeFast Ethernet (10/100)
Power connectorDC-in jack

Network

Networking standardsIEEE 802.1af, IEEE 802.3, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
10G supportNo
Copper ethernet cabling technology100BASE-TX, 10BASE-T
Full duplexYes
Auto MDI/MDI-XYes
Flow control supportYes

Data transmission

MAC address table2048 entries
Switching capacity1.6 Gbit/s
Forwarding rate0.1488 Mpps
Store-and-forwardYes

Design

Product colourBlack
Housing materialMetal
LED indicatorsActivity, Link, PoE, Power

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)150 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)10 - 90%

Weight & dimensions

Width280 mm
Depth179 mm
Height44 mm
Weight1.5 kg

Packaging content

Cables includedAC
ManualYes

Certificates

CertificationFCC Class A, CE

Logistics data

Harmonized System (HS) code85176990
