Intellinet 523776 network switch Managed Black
Model 523776EAN 766623523776
46 specifications
- Speed1 Gbit/s
- Weight1.3 kg
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity8
- 10G supportNo
Overview
- Speed
- 1 Gbit/s
- Weight
- 1.3 kg
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 8
- 10G support
- No
- Brand
- Intellinet
- Category
- Network Switch
- Model
- 523776
- Part number
- 523776
- EAN / UPC
- 766623523776
- Also known as
- Intellinet 523776 network switch Managed Black
Specifications
46 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| SFP module slots quantity | 1 |
| SFP/SFP+ slots quantity | 1 |
| Fiber optic connector | SFP |
| USB 2.0 ports quantity | 0 |
| ExpressCard slot | No |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | No |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-TX, 10BASE-T |
| Port mirroring | Yes |
| Full duplex | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| VLAN support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8192 entries |
| Supported data transfer rates | 10Mbit/s, 100Mbit/s, 1000Mbit/s |
| Switching capacity | 16 Gbit/s |
| Maximum data transfer rate | 1 Gbit/s |
| Jumbo frames support | Yes |
| Packet buffer memory | 0.1758 MB |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNMPv1 |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | No |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | LAN, Link, Power |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 4 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Networking features | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Size (imperial) | 48.3 cm (19") |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 32 - 131 °F |
| Relative humidity | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 266 mm |
| Depth | 183 mm |
| Height | 44 mm |
| Weight | 1.3 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| Manual | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC A, CE Mark, VCCI A |
