Intellinet 505673 network switch Black
Model 505673EAN 766623505673
20 specifications
- Weight740 g
- ColourBlack
- Basic switching RJ-45 Ethernet ports quantity6
- Full duplexYes
- MAC address table8192 entries
- DC input voltage12 - 48 V
Overview
- Weight
- 740 g
- Colour
- Black
- Basic switching RJ-45 Ethernet ports quantity
- 6
- Full duplex
- Yes
- MAC address table
- 8192 entries
- DC input voltage
- 12 - 48 V
- Brand
- Intellinet
- Category
- Network Switch
- Model
- 505673
- Part number
- 505673
- EAN / UPC
- 766623505673
- Also known as
- Intellinet 505673 network switch Black
Specifications
20 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 6 |
| Fiber ports quantity | 2 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x |
| Full duplex | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8192 entries |
| Supported data transfer rates | 10/100 |
| Switching capacity | 5.6 Gbit/s |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| LED indicators | Yes |
Power
| Specification | Value |
|---|---|
| DC input voltage | 12 - 48 V |
| Power consumption (typical) | 9 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 52 mm |
| Depth | 106.1 mm |
| Height | 144.3 mm |
| Weight | 740 g |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC A, EN55022 A, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11, CE/EN60950, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6 |
