Intellinet 4-Port Broadband Router
Model 4-Port Broadband RouterPart no. 524537EAN 766623524537
30 specifications
- Speed0.1 Gbit/s
- ConnectivityWired
- Weight142 g
- ColourBlack
- Quality of Service (QoS) supportNo
- Basic switching RJ-45 Ethernet ports quantity4
Overview
- Speed
- 0.1 Gbit/s
- Connectivity
- Wired
- Weight
- 142 g
- Colour
- Black
- Quality of Service (QoS) support
- No
- Basic switching RJ-45 Ethernet ports quantity
- 4
- Brand
- Intellinet
- Category
- Network Switch
- Model
- 4-Port Broadband Router
- Part number
- 524537
- EAN / UPC
- 766623524537
- Also known as
- Intellinet 4-Port Broadband Router Power over Ethernet (PoE) Black
Specifications
30 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Quality of Service (QoS) support | No |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3 |
| 10G support | No |
| Auto MDI/MDI-X | Yes |
Data transmission
| Specification | Value |
|---|---|
| Supported data transfer rates | 10/100 Mbps |
| Maximum data transfer rate | 0.1 Gbit/s |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP server, DHCP client |
| MAC address filtering | Yes |
Protocols
| Specification | Value |
|---|---|
| Supported network protocols | CSMA/CD, TCP/IP, UDP, ICMP, PPPoE, NTP, NAT, DHCP, DNS, DDNS, ARP |
Design
| Specification | Value |
|---|---|
| Stackable | No |
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Input voltage | 9 V |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 150 x 105 x 27 mm |
| Connectivity technology | Wired |
| Networking features | Fast Ethernet |
| Power requirements | 700mA |
| Wi-Fi | No |
| Connectivity LEDs | Yes |
| Dimensions (W x D x H) (imperial) | 149.9 x 104.1 x 26.9 mm (5.9 x 4.1 x 1.06") |
| Weight (imperial) | 0.141 kg (0.31 lbs) |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Operating temperature (T-T) | 32 - 122 °F |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 142 g |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Class B, CE Mark |
