PoE+ Gigabit Network Switch 5 Port (4x PoE+)
1Gb/s, desktop, metal
Model 32305QEAN 4043718301843
29 specifications
- Speed1000 Mbit/s
- Weight776 g
- ColourBlack
- Basic switching RJ-45 Ethernet ports quantity5
- Copper ethernet cabling technology10BASE-T, 100BASE-T, 1000BASE-T
- Switching capacity1 Gbit/s
Overview
- Speed
- 1000 Mbit/s
- Weight
- 776 g
- Colour
- Black
- Basic switching RJ-45 Ethernet ports quantity
- 5
- Copper ethernet cabling technology
- 10BASE-T, 100BASE-T, 1000BASE-T
- Switching capacity
- 1 Gbit/s
- Brand
- InLine
- Category
- Network Switch
- Model
- 32305Q
- Part number
- 32305Q
- EAN / UPC
- 4043718301843
- Also known as
- InLine PoE+ Gigabit Network Switch 5 Port (4x PoE+), 1Gb/s, desktop, metal
Specifications
29 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Data transmission
| Specification | Value |
|---|---|
| Switching capacity | 1 Gbit/s |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| LED indicators | Link, PoE, Power, Uplink |
Performance
| Specification | Value |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Fanless | Yes |
Power
| Specification | Value |
|---|---|
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Total Power over Ethernet (PoE) budget | 60 W |
Other features
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 5 |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 20 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 160 mm |
| Depth | 122 mm |
| Height | 43 mm |
| Weight | 776 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| Manual | Yes |
