HP JE007A Unmanaged L2 Black
Model JE007APart no. JE007A#*KIT
40 specifications
- ProcessorARM
- Memory128 MB
- Speed56 Gbit/s
- ConnectivityWired
- Weight3.08 kg
- ColourBlack
Overview
- Processor
- ARM
- Memory
- 128 MB
- Speed
- 56 Gbit/s
- Connectivity
- Wired
- Weight
- 3.08 kg
- Colour
- Black
- Brand
- HP
- Category
- Network Switch
- Model
- JE007A
- Part number
- JE007A#*KIT
- Also known as
- HP JE007A Unmanaged L2 Black
Specifications
40 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
| MIB support | IEEE 802.3 |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| SFP module slots quantity | 4 |
| SFP/SFP+ slots quantity | 4 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-TX, 10BASE-T |
| Full duplex | Yes |
| Rate limiting | Yes |
Data transmission
| Specification | Value |
|---|---|
| Supported data transfer rates | 10/100/1000 Mbps |
| Switching capacity | 56 Gbit/s |
| Maximum data transfer rate | 56 Gbit/s |
| Packet buffer memory | 0.512 MB |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP server, DHCP client |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNMP 2c/3 |
Design
| Specification | Value |
|---|---|
| Stackable | No |
| Product colour | Black |
| Housing material | Metal |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor model | ARM |
| Processor frequency | 333 MHz |
| Memory type | RAM |
| Internal memory | 128 MB |
| Flash memory | 128 MB |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Power consumption (typical) | 365 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Data transfer rate | 41.7 Mbit/s |
| Dimensions (WxDxH) | 420 x 442 x 43.2 mm |
| Connectivity technology | Wired |
| Input frequency | 50/60 Hz |
| Networking features | Gigabit Ethernet |
| Power LED | Yes |
| Security features | UL 60950; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1-03 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 3.08 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
