HP E2910-24G al

HP E2910-24G al

Model E2910-24G alPart no. J9145A

69 specifications
  • ProcessorARM11
  • Memory512 MB
  • Speed1 Gbit/s
  • ConnectivityWired
  • Noise53.5 dB
  • Weight4.95 kg
See all specifications

Overview

Processor
ARM11
Memory
512 MB
Speed
1 Gbit/s
Connectivity
Wired
Noise
53.5 dB
Weight
4.95 kg
Brand
HP
Model
E2910-24G al
Part number
J9145A
Also known as
HP E2910-24G al Managed L3

Specifications

69 specifications in 14 groups

Management features

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
Web-based managementYes
System event logYes
MIB supportMIB II, Bridge MIB, RIPv2 MIB, RMONv2 MIB, SMON MIB, Ethernet-Like-MIB, MAU MIB, Entity MIB, Ping MIB

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity20
Combo SFP ports quantity4
SFP/SFP+ slots quantity4

Network

Networking standardsIEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x
10G supportYes
Copper ethernet cabling technology1000BASE-T, 1000BASE-TX, 100BASE-TX, 10BASE-T
Port mirroringYes
Full duplexYes
IP routingYes
Routing entries2000
Auto MDI/MDI-XYes
Broadcast storm controlYes
Flow control supportYes
Link aggregationYes
Rate limitingYes
Spanning tree protocolYes
Number of VLANs256

Data transmission

MAC address table16000 entries
Supported data transfer rates10/100 Mbps
Switching capacity128 Gbit/s
Throughput95 mpps
Number of trunks24
Number of queues8
Maximum data transfer rate1 Gbit/s
Jumbo frames supportYes
Packet buffer memory6 MB

Security

DHCP featuresDHCP server, DHCP client
Access Control List (ACL)Yes
IGMP snoopingYes
MAC address filteringYes
SSH/SSL supportYes
Security algorithms802.1x RADIUS, SSH, SSL/TLS
Static port securityYes

Multicast features

Multicast supportYes

Protocols

Management protocolsIGMPv3, SNMPv1/v2c/v3, XRMON
Data link protocolsLLDP
Supported network protocolsIPv6, UDP, TFTP, ICMP, TCP, ARP, TELNET, BOOTP, SNTP

Design

SafetyEN/IEC, CAN/CSA, UL
Electromagnetic compatibilityFCC, EN, CISPR-22, VCCI

Performance

Built-in processorYes
Processor modelARM11
Processor frequency515 MHz
Memory typeSDRAM
Internal memory512 MB
Flash memory4 MB
Noise level53.5 dB

Power

Input current1.7 A
Input voltage100 - 240 V
Power consumption (typical)82 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Other features

Latency2.9µs/1.3µs
Dimensions (WxDxH)442 x 365.8 x 44 mm
Connectivity technologyWired
Input frequency50/60 Hz
Networking featuresGigabit Ethernet
Wi-FiNo

Operational conditions

Operating temperature (T-T)0 - 55 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)15 - 95%
Storage relative humidity (H-H)15 - 95%
Operating altitude0 - 3000 m
Heat dissipation279 BTU/h

Weight & dimensions

Weight4.95 kg
