HP 2910-48G al
Model 2910-48G alPart no. J9147AABA
49 specifications
- ProcessorARM11
- Memory512 MB
- Type1U
- Weight5.08 kg
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity48
Overview
- Processor
- ARM11
- Memory
- 512 MB
- Type
- 1U
- Weight
- 5.08 kg
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 48
- Brand
- HP
- Category
- Network Switch
- Model
- 2910-48G al
- Part numbers
- J9147AABA, J9147-69001, J9147AR#ABB, J9147A#ABB?TN0/1203, J9147AR, J9147-69001-RFB +1 more
- Also known as
- HP ProCurve 2910-48G al Managed L3 Gigabit Ethernet (10/100/1000) 1U
Specifications
49 specifications in 12 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| System event log | Yes |
| MIB support | MIB II, Bridge MIB, RIPv2 MIB, RMONv2 MIB, SMON MIB, RADIUS Client MIB, RADIUS Accounting MIB, Ethernet-Like-MIB, MAU MIB, Entity MIB, Ping MIB |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | 4 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| 10G support | Yes |
| Port mirroring | Yes |
| Full duplex | Yes |
| Routing entries | 2000 |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Rate limiting | Yes |
| Spanning tree protocol | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 16000 entries |
| Switching capacity | 176 Gbit/s |
| Throughput | 131 Mpps |
| Latency (1 Gbps) | 2.9 µs |
| Latency (10 Gbps) | 1.3 µs |
| Packet buffer memory | 6 MB |
Security
| Specification | Value |
|---|---|
| Access Control List (ACL) | Yes |
| MAC address filtering | Yes |
| SSH/SSL support | Yes |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Form factor | 1U |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor model | ARM11 |
| Processor frequency | 515 MHz |
| Internal memory | 512 MB |
| Flash memory | 4 MB |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 2.1 A |
| Power consumption (typical) | 105 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 55 °C |
| Operating altitude | 0 - 3000 m |
| Heat dissipation | 356 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 442.5 mm |
| Depth | 365.8 mm |
| Height | 44 mm |
| Weight | 5.08 kg |
