HP 2910-24G-PoE+ al

HP 2910-24G-PoE+ al

Model 2910-24G-PoE+ alPart no. J9146-69001

42 specifications
  • Type1U
  • Weight5.6 kg
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity24
  • 10G supportYes
  • MAC address table16000 entries
See all specifications

Overview

Type
1U
Weight
5.6 kg
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
24
10G support
Yes
MAC address table
16000 entries
Brand
HP
Model
2910-24G-PoE+ al
Part numbers
J9146-69001, J9146AR#ABB, J9146A#ABA?A1, J9146AABA
Also known as
HP ProCurve 2910-24G-PoE+ al Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U

Specifications

42 specifications in 11 groups

Management features

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
Web-based managementYes
System event logYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Combo SFP ports quantity4

Network

Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
10G supportYes
Port mirroringYes
Full duplexYes
Routing entries2000
Auto MDI/MDI-XYes
Flow control supportYes
Link aggregationYes
Rate limitingYes
Spanning tree protocolYes

Data transmission

MAC address table16000 entries
Switching capacity128 Gbit/s
Throughput95 Mpps
Latency (1 Gbps)2.9 µs
Latency (10 Gbps)1.3 µs

Security

Access Control List (ACL)Yes
MAC address filteringYes
SSH/SSL supportYes

Multicast features

Multicast supportYes

Design

Rack mountingYes
StackableYes
Form factor1U

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current6.1 A
Power consumption (typical)490 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes

Operational conditions

Operating temperature (T-T)0 - 55 °C
Operating altitude0 - 3000 m
Heat dissipation447 BTU/h

Weight & dimensions

Width442 mm
Depth365.8 mm
Height44 mm
Weight5.6 kg
