HP 2510-48 + UR954E
Model 2510-48 + UR954EPart no. J9020A UR954E
42 specifications
- ProcessorMIPS
- Memory128 MB
- Speed1 Gbit/s
- ConnectivityWired
- Noise43.6 dB
- Weight2.74 kg
Overview
- Processor
- MIPS
- Memory
- 128 MB
- Speed
- 1 Gbit/s
- Connectivity
- Wired
- Noise
- 43.6 dB
- Weight
- 2.74 kg
- Brand
- HP
- Category
- Network Switch
- Model
- 2510-48 + UR954E
- Part number
- J9020A UR954E
- Also known as
- HP 2510-48 + UR954E
Specifications
42 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Gigabit Ethernet (copper) ports quantity | 2 |
| Console port | RJ-45 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| 10G support | No |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-T, 100BASE-TX, 10BASE-T |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
Optical fiber
| Specification | Value |
|---|---|
| Transmission distance (max) | 4.6 km |
Data transmission
| Specification | Value |
|---|---|
| Supported data transfer rates | 10/100/1000 Mbps |
| Switching capacity | 17.6 Gbit/s |
| Throughput | 13M ppc |
| Maximum data transfer rate | 1 Gbit/s |
| Packet buffer memory | 0.5 MB |
Design
| Specification | Value |
|---|---|
| LED indicators | LAN, Power |
| Safety | SA 22.2 No. 60950, UL 60950-1, IEC 60950, EN 60950 |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor model | MIPS |
| Processor frequency | 300 MHz |
| Memory type | SDRAM |
| Internal memory | 128 MB |
| Flash memory | 16 MB |
| Noise level | 43.6 dB |
Power
| Specification | Value |
|---|---|
| Input current | 0.7 - 1.2 A |
| Input voltage | 100 - 240 V |
| Power consumption (typical) | 27 W |
Other features
| Specification | Value |
|---|---|
| Management platform | HP PCM+, HP PCM |
| Latency | <4.9 µs @ 100Mb; <2.9 µs @ 1000Mb |
| Dimensions (WxDxH) | 236.2 x 442.5 x 43.9 mm |
| Connectivity technology | Wired |
| Input frequency | 50/60 Hz |
| Networking features | Gigabit Ethernet |
| Power LED | Yes |
| Wi-Fi | No |
| Connectivity LEDs | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 15 - 95% |
| Operating altitude | 0 - 4600 m |
| Heat dissipation | 92 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.74 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC |
