Fujitsu PRIMERGY BX
Model PRIMERGY BXPart no. S26361-K1533-V100
29 specifications
- Memory256 MB
- Weight1.5 kg
- ColourMulticolour
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports typeNo
- 10G supportYes
Overview
- Memory
- 256 MB
- Weight
- 1.5 kg
- Colour
- Multicolour
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports type
- No
- 10G support
- Yes
- Brand
- Fujitsu
- Category
- Network Switch
- Model
- PRIMERGY BX
- Part number
- S26361-K1533-V100
- Also known as
- Fujitsu PRIMERGY BX Managed L2+ Multicolour
Specifications
29 specifications in 11 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2+ |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports type | No |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Installed QSFP+ modules quantity | 1 |
| SFP+ module slots quantity | 8 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Port mirroring | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| VLAN support | Yes |
Optical fiber
| Specification | Value |
|---|---|
| Fiber ethernet cabling technology | 1000BASE‑SX |
| Switching optical modules type | 40 Gigabit Ethernet |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Product colour | Multicolour |
| LED indicators | Link, Power, Status |
Performance
| Specification | Value |
|---|---|
| Internal memory | 256 MB |
| Flash memory | 64 MB |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 40 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 192.6 mm |
| Depth | 267.9 mm |
| Height | 28 mm |
| Weight | 1.5 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, GS, ULc/us, FCC, CB, RoHS, WEEE, VCCI, C-Tick, BSMI |
