Fujitsu Brocade ICX6450-24

Fujitsu Brocade ICX6450-24

Model Brocade ICX6450-24Part no. S26361-K1477-V110

45 specifications
  • Noise37.9 dB
  • Weight3.35 kg
  • ColourBlack
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity24
  • 10G supportYes
See all specifications

Overview

Noise
37.9 dB
Weight
3.35 kg
Colour
Black
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
24
10G support
Yes
Brand
Fujitsu
Model
Brocade ICX6450-24
Part number
S26361-K1477-V110
Also known as
Fujitsu Brocade ICX6450-24 Managed L3 Gigabit Ethernet (10/100/1000) Black

Specifications

45 specifications in 13 groups

Management features

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
Web-based managementYes
ARP inspectionYes
MIB supportYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)

Network

Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportYes
Port mirroringYes
Auto MDI/MDI-XYes
Spanning tree protocolYes
Number of VLANs4096

Data transmission

MAC address table16000 entries
Switching capacity128 Gbit/s
Number of trunks124
Number of queues8
Jumbo frames supportYes

Security

DHCP featuresDHCP server
Access Control List (ACL)Yes
IGMP snoopingYes
Security algorithms802.1x RADIUS, AES, SSH, SSH-2

Multicast features

Multicast supportYes

Protocols

Management protocolsSNMPv1/v2c, SNMPv3
Switching protocolsVSRP, VRRP, MRP

Design

Rack mountingYes
StackableYes
Product colourBlack

Performance

Noise level37.9 dB
Mean time between failures (MTBF)906243 h

Power

Power supply includedYes
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current1.5 A
Power consumption (typical)65 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)5 - 95%
Non-operating altitude0 - 3000 m

Weight & dimensions

Width443 mm
Depth240 mm
Height43.4 mm
Weight3.35 kg
