48-Port Stackable Layer 3 Switch
Model ECS8854FEAN 655216012233
51 specifications
- Memory4 MB
- Type1U
- Weight6.6 kg
- ColourBlack
- Switch typeManaged
- SFP+ module slots quantity48
Overview
- Memory
- 4 MB
- Type
- 1U
- Weight
- 6.6 kg
- Colour
- Black
- Switch type
- Managed
- SFP+ module slots quantity
- 48
- Brand
- EnGenius
- Category
- Network Switch
- Model
- ECS8854F
- Part number
- ECS8854F
- EAN / UPC
- 655216012233
- Also known as
- EnGenius 48-Port Stackable Layer 3 Switch
Specifications
51 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
| Cloud-managed | Yes |
| Web-based management | Yes |
| ARP inspection | Yes |
| System event log | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| SFP+ module slots quantity | 48 |
| Console port | RJ-45 |
| QSFP28 ports quantity | 6 |
| USB 2.0 ports quantity | 1 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3z, IEEE 802.3ae, IEEE 802.1p |
| 10G support | Yes |
| Routing entries | 1500 |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 32000 entries |
| Switching capacity | 1680 Gbit/s |
| Forwarding rate | 600 Mpps |
| Static route | Yes |
| Jumbo frames support | Yes |
| Jumbo frames | 10000 |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP relay, DHCP server, DHCP client |
| Access Control List (ACL) | Yes |
| IGMP entries | 4000 |
| IGMP snooping | Yes |
Multicast features
| Specification | Value |
|---|---|
| Multicast Listener Discovery (MLD) snooping | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Yes |
| Number of fans | 3 fan(s) |
Performance
| Specification | Value |
|---|---|
| Memory type | DDR4-SDRAM |
| Internal memory | 4 MB |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power supply included | Yes |
| Number of power supply units | 2 |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 442 mm |
| Depth | 450 mm |
| Height | 45 mm |
| Weight | 6.6 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 538 mm |
| Package depth | 644 mm |
| Package height | 162 mm |
| Package weight | 9.65 kg |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
