Cloud Managed Switch 12xSFP+ L2+
19" 1/2 rack 1U
Model ECS5512FEAN 655216010772
48 specifications
- Memory512 MB
- Weight1.36 kg
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity0
- Full duplexYes
Overview
- Memory
- 512 MB
- Weight
- 1.36 kg
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 0
- Full duplex
- Yes
- Brand
- EnGenius
- Category
- Network Switch
- Model
- ECS5512F
- Part number
- ECS5512F
- EAN / UPC
- 655216010772, 4713361935978, 7071320166229
- Also known as
- EnGenius Cloud Managed Switch 12xSFP+ L2+ 19" 1/2 rack 1U
Specifications
48 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2+ |
| Quality of Service (QoS) support | Yes |
| Cloud-managed | Yes |
| Web-based management | Yes |
| Configuring Location Settings (CLI) | Yes |
| System event log | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | No |
| Installed SFP+ modules quantity | 0 |
| SFP+ module slots quantity | 12 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
| Full duplex | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| VLAN support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 32000 entries |
| Switching capacity | 240 Gbit/s |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP server, DHCPv6 client |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Memory type | SDRAM |
| Internal memory | 512 MB |
| Flash memory | 128 MB |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 210 mm |
| Depth | 230 mm |
| Height | 44 mm |
| Weight | 1.36 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 350 mm |
| Package depth | 380 mm |
| Package height | 130 mm |
| Package weight | 2.6 kg |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case net weight | 10.4 kg |
| Master (outer) case width | 345 mm |
| Master (outer) case length | 550 mm |
| Master (outer) case height | 380 mm |
| Master (outer) case gross weight | 11 kg |
| Products per master (outer) case | 4 pc(s) |
