Dell Force10 Z9500 L2/L3 Black
Model Z9500Part no. 210-ABVIEAN 5397063839278
25 specifications
- Weight55.3 kg
- ColourBlack
- Switch layerL2/L3
- Basic switching RJ-45 Ethernet ports typeNo
- 10G supportYes
- Switching optical modules type40 Gigabit Ethernet
Overview
- Weight
- 55.3 kg
- Colour
- Black
- Switch layer
- L2/L3
- Basic switching RJ-45 Ethernet ports type
- No
- 10G support
- Yes
- Switching optical modules type
- 40 Gigabit Ethernet
- Brand
- Dell
- Category
- Network Switch
- Model
- Z9500
- Part numbers
- 210-ABVI, 210-ACZD
- EAN / UPC
- 5397063839278, 5397063839285
- Also known as
- DELL Force10 Z9500 L2/L3 Black
Specifications
25 specifications in 10 groups
Management features
| Specification | Value |
|---|---|
| Switch layer | L2/L3 |
| MIB support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports type | No |
| Console port | RJ-45 |
| USB 2.0 ports quantity | 2 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1ab, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3u, IEEE 802.3x |
| 10G support | Yes |
| Copper ethernet cabling technology | 1000BASE-T |
Optical fiber
| Specification | Value |
|---|---|
| Switching optical modules type | 40 Gigabit Ethernet |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Product colour | Black |
| Number of fans | 5 fan(s) |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 3100 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 433.8 mm |
| Depth | 863.6 mm |
| Height | 133.3 mm |
| Weight | 55.3 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
