Dell Force10 S6000 Managed L2/L3 1U Black
Model S6000Part no. 210-AEJCEAN 5397063839254
41 specifications
- Memory4096 MB
- Type1U
- Weight7.32 kg
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity32
Overview
- Memory
- 4096 MB
- Type
- 1U
- Weight
- 7.32 kg
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 32
- Brand
- Dell
- Category
- Network Switch
- Model
- S6000
- Part numbers
- 210-AEJC, 210-AAUB, 210-AAUC, 210-AAUD, 210-AAUE, 210-AEJB
- EAN / UPC
- 5397063839254, 5397063839216, 5397063839223, 5397063839230 +2 more
- Also known as
- DELL Force10 S6000 Managed L2/L3 1U Black
Specifications
41 specifications in 10 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
| MIB support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 32 |
| Fiber optic connector | QSFP+ |
| Console port | RJ-45 |
| USB 2.0 ports quantity | 2 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Yes |
| Full duplex | Yes |
| IP routing | Yes |
| Routing entries | 16000 |
| IP address table | 24000 |
| Link aggregation | Yes |
| Number of VLANs | 4000 |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 160000 entries |
| Switching capacity | 2560 Gbit/s |
| Throughput | 1462 Mpps |
| Latency (10 Gbps) | 0.6 µs |
| Packet buffer memory | 12 MB |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Form factor | 1U |
| Product colour | Black |
| Number of fans | 3 fan(s) |
Performance
| Specification | Value |
|---|---|
| Internal memory | 4096 MB |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 220 W |
| Power consumption (max) | 371 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 433.8 mm |
| Depth | 460 mm |
| Height | 43.5 mm |
| Weight | 7.32 kg |
