S-Series S5212F-ON Managed L2/L3 1U Black
Model S5212F-ONPart no. DNS5212F_INDUSTRY-STANDARDEAN 884116330912
55 specifications
- Memory16000 MB
- Type1U
- OSOS10
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity0
Overview
- Memory
- 16000 MB
- Type
- 1U
- OS
- OS10
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 0
- Brand
- Dell
- Category
- Network Switch
- Model
- S5212F-ON
- Part numbers
- DNS5212F_INDUSTRY-STANDARD, S5212F_1.4, 210-APHW-BVFK, S5212F-FY26Q1-MX, S5212F272, S5212F-ONF +1 more
- EAN / UPC
- 884116330912, 884116485360, 884116417354, 5397184224397
- Also known as
- DELL S-Series S5212F-ON Managed L2/L3 1U Black
Specifications
55 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | No |
| Gigabit Ethernet (copper) ports quantity | 1 |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Fiber optic connector | QSFP28, SFP28 |
| Console port | RJ-45/Micro-USB |
| QSFP28 ports quantity | 3 |
| SFP28 ports quantity | 12 |
| USB 2.0 ports quantity | 1 |
| Power connector | AC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3 |
| 10G support | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| VLAN support | Yes |
| Number of VLANs | 4000 |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 160000 entries |
| Switching capacity | 2160 Gbit/s |
| Forwarding rate | 892 Mpps |
| Packet buffer memory | 32 MB |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Protocols
| Specification | Value |
|---|---|
| Management protocols | CLI, SNMP, REST API’s |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Supported network protocols | IPv4 e IPv6 Roteamente Estático, RIP, OSPFv2 ,OSPFv3, BGP e IS-IS |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Yes |
| Number of fans | 4 fan(s) |
Performance
| Specification | Value |
|---|---|
| Operating system installed | OS10 |
| Built-in processor | Yes |
| Memory type | SDRAM |
| Internal memory | 16000 MB |
| Compatible operating systems | Debian Linux version 9 Linux Kernel 4.9 OS10 |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power supply included | Yes |
| AC input voltage | 250 V |
| AC input frequency | 50/60 Hz |
| Input current | 12 A |
| Power consumption (max) | 304 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Packaging content | 2x 250 V, 2 metros, NBR 14136/C13 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 199.8 mm |
| Depth | 406.4 mm |
| Height | 43.6 mm |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
