S-Series S4048T-ON Managed L2/L3
10G Ethernet (100/1000/10000) 1U Black
Model S4048T-ONPart no. 210-AHMREAN 5397184223116
60 specifications
- Memory4000 MB
- Type1U
- Weight10.4 kg
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity48
Overview
- Memory
- 4000 MB
- Type
- 1U
- Weight
- 10.4 kg
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 48
- Brand
- Dell
- Category
- Network Switch
- Model
- S4048T-ON
- Part numbers
- 210-AHMR, DNS4048T, NET-S4048-00276
- EAN / UPC
- 5397184223116
- Also known as
- DELL S-Series S4048T-ON Managed L2/L3 10G Ethernet (100/1000/10000) 1U Black
Specifications
60 specifications in 15 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| QSFP+ module slots quantity | 6 |
| Console port | RJ-45/Micro-USB |
| USB 2.0 ports quantity | 1 |
| Power connector | AC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Yes |
| Copper ethernet cabling technology | 10GBASE-T |
| Cable types supported | Cat6, Cat6a, Cat7 |
| Port mirroring | Yes |
| Address Resolution Protocol (ARP) entries (max) | 128000 |
| Link aggregation | Yes |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
Optical fiber
| Specification | Value |
|---|---|
| Switching optical modules type | 40 Gigabit Ethernet |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 160000 entries |
| Switching capacity | 1440 Gbit/s |
| Forwarding rate | 1080 Mpps |
| Jumbo frames support | Yes |
| Maximum transmission unit (MTU) range | 8 - 9216 B |
| Packet buffer memory | 16 MB |
Security
| Specification | Value |
|---|---|
| Security algorithms | 802.1x RADIUS, AES, EAP, IPSec, SNMP |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Protocols
| Specification | Value |
|---|---|
| Management protocols | CLI, SNMP, REST, API’s |
| GARP VLAN Registration Protocol (GVRP) | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Yes |
| Backlight display | Yes |
| Display type | LED |
| Number of fans | 4 fan(s) |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Internal memory | 4000 MB |
| List of RFCs | IP, IPv4, IPv6, RIP, OSPF, IS-IS, BGP |
Power
| Specification | Value |
|---|---|
| Power supply included | Yes |
| Redundant power supply (RPS) support | Yes |
| Number of power supply units | 2 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 338 W |
| Power consumption (max) | 460 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | 40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Heat dissipation | 1568 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 434 mm |
| Depth | 460 mm |
| Height | 43.5 mm |
| Weight | 10.4 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | RoHS |
