Dell S-Series S4048-ON Managed L2/L3 1U Black
Model S4048-ONPart no. DNS4048EAN 5397063839209
68 specifications
- Memory4000 MB
- Noise59.6 dB
- Type1U
- Weight8.4 kg
- ColourBlack
- Switch typeManaged
Overview
- Memory
- 4000 MB
- Noise
- 59.6 dB
- Type
- 1U
- Weight
- 8.4 kg
- Colour
- Black
- Switch type
- Managed
- Brand
- Dell
- Category
- Network Switch
- Model
- S4048-ON
- Part numbers
- DNS4048, DNS4048RA, 210-ADUX, 210-ADVB, 210-ADUW, 210-ADUZ
- EAN / UPC
- 5397063839209, 4053162981768, 5397063839193
- Also known as
- DELL S-Series S4048-ON Managed L2/L3 1U Black
Specifications
68 specifications in 16 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| System event log | Yes |
| MIB support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | No |
| SFP+ module slots quantity | 48 |
| QSFP+ module slots quantity | 6 |
| Console port | RJ-45/Micro-USB |
| USB 2.0 ports quantity | 1 |
| Power connector | AC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Yes |
| Port mirroring | Yes |
| Full duplex | Yes |
| Routing entries | 128000 |
| Flow control support | Yes |
| Link aggregation | Yes |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 160000 entries |
| Switching capacity | 1440 Gbit/s |
| Forwarding rate | 1080 Mpps |
| Latency (10 Gbps) | 600 µs |
| Number of queues | 8 |
| Packet buffer memory | 12 MB |
Security
| Specification | Value |
|---|---|
| Access Control List (ACL) egress | 1000 |
| Access Control List (ACL) ingress | 2500 |
| Security algorithms | 802.1x RADIUS, AES, EAP |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SMIv1, SMIv2, SNMPv1, SNMPv2, SNMPv3, IGMPv1, IGMPv2, IGMPv3, OSPF, OSPFv2, OSPFv3, RIPv1, RIPv2, RMON |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Supported network protocols | IPv4, IPv6, LLDP, STP, PFC, ETS, MSTP, RSTP, UDP, TCP, Telnet, FTP, ICMP, ARP, DNS, NTPv3, CIDR, BOOTP, VRRP, MLD, MLDv2, TACACS, SSH, BGPv6, IS-IS, MD5, BGP-4, MSDP |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Yes |
| Ventilation system | Front-to-back airflow |
| Safety | UL/CSA 60950-L, EN 60950-1, IEC 60950-1, EN 60825-1, EN 60825-2, FDA 21 CFR 1040.10/1040.11 |
Performance
| Specification | Value |
|---|---|
| Physical stacking (units) | 6 |
| Built-in processor | Yes |
| Internal memory | 4000 MB |
| Noise level | 59.6 dB |
Power
| Specification | Value |
|---|---|
| Power supply included | Yes |
| Redundant power supply (RPS) support | Yes |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 2.3 A |
| Power consumption (typical) | 153 W |
| Power consumption (max) | 234.35 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
| Heat dissipation | 799.64 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 434 mm |
| Depth | 460 mm |
| Height | 43.5 mm |
| Weight | 8.4 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| Manual | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | ASNZS CISPR 22, ICES-003, EN 55022, VCCI V3, EN300 386 V1.4.1, EN 55024, EN 61000-3-2, EN 61000-3-3, EN61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
