Dell PowerConnect 5448P
Model PowerConnect 5448PPart no. 13577430
50 specifications
- Memory64 MB
- Speed1 Gbit/s
- ConnectivityWired
- Weight3.6 kg
- ColourBlack
- Switch typeManaged
Overview
- Memory
- 64 MB
- Speed
- 1 Gbit/s
- Connectivity
- Wired
- Weight
- 3.6 kg
- Colour
- Black
- Switch type
- Managed
- Brand
- Dell
- Category
- Network Switch
- Model
- PowerConnect 5448P
- Part number
- 13577430
- Also known as
- DELL PowerConnect 5448P Managed L3 Black
Specifications
50 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| System event log | Yes |
| MIB support | FC 1213 MIB II, RFC 1215, RFC 1286, RFC 1442 SMIv2, RFC 1451, RFC 1492 TACACS+, RFC 1493, RFC 1573, RFC 1643, RFC 1757, RFC 1907, RFC 2011, RFC 2012, RFC 2013, RFC 2233, RFC 2618, RFC 2665, RFC 2666, RFC 2674, RFC 2737, RFC 2819, RFC 2863, Dell 5424 |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| SFP module slots quantity | 4 |
| SFP/SFP+ slots quantity | 4 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.2, IEEE 802.3, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3I, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | No |
| Port mirroring | Yes |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Broadcast storm control | Yes |
| Flow control support | Yes |
| Spanning tree protocol | Yes |
| Number of VLANs | 4000 |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
| Supported data transfer rates | 10/100/1000 Mbps |
| Switching capacity | 96 Gbit/s |
| Throughput | 71.2 Mpps |
| Number of queues | 8 |
| Maximum data transfer rate | 1 Gbit/s |
| Packet buffer memory | 6 MB |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP server, DHCP client |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| MAC address filtering | Yes |
| SSH/SSL support | Yes |
| Security algorithms | 802.1x RADIUS |
| Static port security | Yes |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNMPv1, SNMP v2c, RMON, TFTP, CLI, Telnet, SNTP, BootP/DHCP |
| Data link protocols | Ethernet |
Design
| Specification | Value |
|---|---|
| Stackable | No |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Internal memory | 64 MB |
| Flash memory | 16 MB |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 440 x 255 x 44 mm |
| Connectivity technology | Wired |
| Authentication method | RADIUS, TACACS+ |
| Networking features | Gigabit Ethernet |
| Dimensions (W x D x H) (imperial) | 439.9 x 254.5 x 43.9 mm (17.3 x 10 x 1.73") |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 3.6 kg |
