Dell PowerConnect 2808
Model PowerConnect 2808Part no. 210-27775-3NBD
32 specifications
- Speed1 Gbit/s
- ConnectivityWired
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity8
- Port mirroringYes
- MAC address table8000 entries
Overview
- Speed
- 1 Gbit/s
- Connectivity
- Wired
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 8
- Port mirroring
- Yes
- MAC address table
- 8000 entries
- Brand
- Dell
- Category
- Network Switch
- Model
- PowerConnect 2808
- Part numbers
- 210-27775-3NBD, 210-27775-1NBD, 210-27775-3Y4H
- Also known as
- DELL PowerConnect 2808 Unmanaged
Specifications
32 specifications in 10 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| MIB support | RFC 1213 – MIB II (RFC’s 2011, 2012, 2013) |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Port mirroring | Yes |
| Auto MDI/MDI-X | Yes |
| Broadcast storm control | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
| Supported data transfer rates | 10/100/1000 Mbps |
| Switching capacity | 16 Gbit/s |
| Throughput | 11.9 Mpps |
| Maximum data transfer rate | 1 Gbit/s |
| Jumbo frames support | Yes |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP server, DHCP client |
| IGMP snooping | Yes |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SMI v1, SNMP, Telnet, SMI v2, TFTP, IP, ICMP, TCP, BOOTP, DHCP |
| Data link protocols | Ethernet |
| Supported network protocols | IGMPv2, GARP, GVRP, GMP, IPv6 |
Design
| Specification | Value |
|---|---|
| Stackable | Yes |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 265.5 x 161.7 x 43.2 mm |
| Connectivity technology | Wired |
| Networking features | Gigabit Ethernet |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 95% |
