Dell Networking S3048-ON with reversed Air-Flow

Model Networking S3048-ON with reversed Air-FlowPart no. 210-AEDPEAN 5397063839186

60 specifications

Overview

Brand: Dell
Category: Network Switch
Model: Networking S3048-ON with reversed Air-Flow
Part number: 210-AEDP
EAN / UPC: 5397063839186
Also known as: DELL S-Series Networking S3048-ON with reversed Air-Flow Managed L2/L3 Gigabit Ethernet (10/100/1000) 1U Black

60 specifications in 14 groups

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity	4
Console port	RJ-45
USB 2.0 ports quantity	1

Specification	Value
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	Yes
Copper ethernet cabling technology	1000BASE-T, 1000BASE-TX, 100BASE-T
Full duplex	Yes
Routing entries	16000
Flow control support	Yes
Link aggregation	Yes
VLAN support	Yes

Specification	Value
Multicast support	Yes

Specification	Value
Management protocols	SMIv1, SMIv2, SNMPv1, SNMPv2, SNMPv3, OSPF, OSPFv2, OSPFv3, IGMPv1, IGMPv2, IGMPv3, RMON, RMONv2
Supported network protocols	IPv4, IPv6, ICMP, ARP, DNS, LLDP, MSTP, RSTP, UDP, TCP, Telnet, FTP, NTPv3, TACACS, CIDR, BOOTP, MLD, MLDv2, RIPv1, RIPv2, OSPFv2, OSPFv3, NSSA, MD5, MSDP, SSH

Specification	Value
Power supply included	Yes
Redundant power supply (RPS) support	Yes
Number of power supply units	1
AC input voltage	90 - 264 V
AC input frequency	50 - 60 Hz
Input current	1 A
Power consumption (typical)	65 W
Power consumption (max)	87 W

Specification	Value
Power over Ethernet (PoE)	No

Specification	Value
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 85%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3048 m
Heat dissipation	290 BTU/h

Specification	Value
Certification	ASNZS CISPR 22, ICES-003, EN 55022, VCCI V3, EN300 386 V1.4.1, EN 55024, EN 61000-3-2, EN 61000-3-3, EN61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, RoHS

Specification	Value
Harmonized System (HS) code	85176990
