Dell N4064F + 5YNBD

Dell N4064F + 5YNBD

Model N4064F + 5YNBDPart no. 210-ABVW-5YNBD

47 specifications
  • Type1U
  • Weight10.6 kg
  • ColourBlack
  • Switch typeManaged
  • Console portRJ-45
  • 10G supportYes
See all specifications

Overview

Type
1U
Weight
10.6 kg
Colour
Black
Switch type
Managed
Console port
RJ-45
10G support
Yes
Brand
Dell
Model
N4064F + 5YNBD
Part number
210-ABVW-5YNBD
Also known as
DELL PowerConnect N4064F + 5YNBD Managed L3 1U Black

Specifications

47 specifications in 14 groups

Management features

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
MIB supportYes

Ports & interfaces

Console portRJ-45
USB 2.0 ports quantity1

Network

Networking standardsIEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportYes
Port mirroringYes
Full duplexYes
Auto MDI/MDI-XYes
Broadcast storm controlYes
Flow control supportYes
Link aggregationYes
Spanning tree protocolYes
Number of VLANs4096

Data transmission

MAC address table131072 entries
Switching capacity1280 Gbit/s
Throughput952 Mpps
Number of static routes1024
Packet buffer memory9 MB

Security

Access Control List (ACL)Yes
IGMP snoopingYes
SSH/SSL supportYes

Multicast features

Multicast supportYes

Protocols

Management protocolsSNMPv1/2/3
Supported network protocolsTCP, UDP, HTTP

Design

Rack mountingYes
StackableYes
Form factor1U
Product colourBlack

Performance

Flash memory256 MB
Firmware upgradeableYes

Power

Redundant power supply (RPS) supportYes
Number of power supply units2
Power consumption (max)220 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)0 - 90%
Storage relative humidity (H-H)0 - 95%
Heat dissipation754.82 BTU/h

Weight & dimensions

Width433.8 mm
Depth460 mm
Height43.4 mm
Weight10.6 kg

Certificates

CertificationACMA RCA, ICES, CCC, CE, VCCI, FCC, NRTL UL, EAC, GS, WEEE, RoHS, REACH, JEL
