1000) 1U Black

Model N1124T-ONEAN 884116301288

67 specifications

Overview

Brand: Dell
Category: Network Switch
Model: N1124T-ON
Part numbers: N1124T-ON, DN_N1124TARV1, DN_N1124_LTD, DN_N1124TANV1, 210-AJIS, DN_N1124_1
EAN / UPC: 884116301288, 5397184011492, 884116349549
Also known as: DELL N-Series N1124T-ON Managed L2 Gigabit Ethernet (10/100/1000) 1U Black

67 specifications in 15 groups

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
ARP inspection	Yes
MIB support	SMIv1/SMIv2, IP, TCP, UDP

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity	4
Console port	Micro-USB
USB 2.0 ports quantity	1

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	Yes
Port mirroring	Yes
Full duplex	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Broadcast storm control	Yes
Flow control support	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Private VLAN, Tagged VLAN, Protocol-based VLAN
Number of VLANs	512

Specification	Value
Access Control List (ACL)	Yes
Access Control List (ACL) rules	4000
IGMP snooping	Yes
Authentication type	RADIUS
BPDU filtering/protection	Yes
SSH/SSL support	Yes
Security algorithms	802.1x RADIUS, SSH, SSL/TLS

Specification	Value
Multicast support	Yes

Specification	Value
Power over Ethernet (PoE)	No

Specification	Value
Power supply	40 W

Specification	Value
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 85%
Heat dissipation	65.85 BTU/h

Specification	Value
Cables included	AC
Manual	Yes

Specification	Value
Compliance certificates	RoHS
Certification	ACMA RCM Class A ICES Class A; cUL CCC Class A; NAL CE Class A VCCI Class A FCC Class A; NRTL UL; FDA 21 CFR 1040.10 EAC GS mark RoHS JEL
