Dell PowerConnect 8024F Managed L3

Dell PowerConnect 8024F Managed L3

10G Ethernet (100/1000/10000) 1U Black

Model 8024FPart no. 210-30322-3NBD

53 specifications
  • Speed10 Gbit/s
  • ConnectivityWired
  • Type1U
  • ColourBlack
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity24
See all specifications

Overview

Speed
10 Gbit/s
Connectivity
Wired
Type
1U
Colour
Black
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
24
Brand
Dell
Model
8024F
Part numbers
210-30322-3NBD, 210-30322-3Y4H, 210-30322-5NBD, 210-30322-5Y4H
Also known as
DELL PowerConnect 8024F Managed L3 10G Ethernet (100/1000/10000) 1U Black

Specifications

53 specifications in 12 groups

Management features

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
MIB supportRIPv1/2, OSPFv1/2/3, CIDR, ICMP, IRDP, VRRP, ARP, DVMRP

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports type10G Ethernet (100/1000/10000)
SFP+ module slots quantity24
Power connectorDC-in jack

Network

Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qbb, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x
10G supportYes
Copper ethernet cabling technology1000BASE-T, 1000BASE-TX, 100BASE-TX, 10BASE-T, 10GBASE-T
Full duplexYes
IP routingYes
Auto MDI/MDI-XYes
Flow control supportYes
Link aggregationYes
Rate limitingYes
Spanning tree protocolYes
Number of VLANs4000

Data transmission

MAC address table32000 entries
Supported data transfer rates10/100/1000 Mbps
Switching capacity480 Gbit/s
Number of queues8
Maximum data transfer rate10 Gbit/s
Jumbo frames supportYes

Security

DHCP featuresDHCP server, DHCP client
IGMP snoopingYes
MAC address filteringYes
SSH/SSL supportYes
Security algorithms802.1x RADIUS, HTTPS, SSH, SSL/TLS

Multicast features

Multicast supportYes

Protocols

Management protocolsIGMPv2, SNMPv1/2/3, MLDv1/2
Switching protocolsLACP
Data link protocolsSSH, LLDP
Supported network protocolsIPv4, IPv6, HTTP, TCP/UDP, DSCP

Design

Rack mountingYes
Form factor1U
Product colourBlack
LED indicatorsYes

Power

AC input frequency50 - 60 Hz
Input current23.7 A
Input voltage110 - 240 V
Power consumption (typical)160.78 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Other features

Connectivity technologyWired
Networking featuresGigabit Ethernet
Power requirements110-240V, 50-60 Hz

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)10 - 95%
Operating temperature (T-T)32 - 104 °F
Heat dissipation548.66 BTU/h
