Dell PowerConnect 2824 Managed L2/L3 Gigabit Ethernet (10/100/1000) 1U Black

Dell PowerConnect 2824 Managed L2/L3 Gigabit Ethernet (10/100/1000) 1U Black

Model 2824Part no. 210-27777-1PEAN 5742220744757

37 specifications
  • Type1U
  • Weight3.04 kg
  • ColourBlack
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity24
  • Copper ethernet cabling technology1000BASE-T, 100BASE-T, 10BASE-T
See all specifications

Overview

Type
1U
Weight
3.04 kg
Colour
Black
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
24
Copper ethernet cabling technology
1000BASE-T, 100BASE-T, 10BASE-T
Brand
Dell
Model
2824
Part numbers
210-27777-1P, 210-27777-1P2M, 210-27777-1P4H, 210-27777-1P4M, 210-27777-1P8M, 210-27777-1YNB +22 more
EAN / UPC
5742220744757, 5415247025443
Also known as
DELL PowerConnect 2824 Managed L2/L3 Gigabit Ethernet (10/100/1000) 1U Black

Specifications

37 specifications in 11 groups

Management features

Switch typeManaged
Switch layerL2/L3
Quality of Service (QoS) supportYes
Web-based managementYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
SFP module slots quantity2
SFP/SFP+ slots quantity2
Power connectorDC-in jack

Network

Networking standardsIEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3x
Copper ethernet cabling technology1000BASE-T, 100BASE-T, 10BASE-T
Port mirroringYes
Auto MDI/MDI-XYes
Broadcast storm controlYes
Flow control supportYes
Link aggregationYes

Data transmission

MAC address table8000 entries
Switching capacity48 Gbit/s
Throughput35.6 Mpps
Jumbo frames supportYes

Security

DHCP featuresDHCP server, DHCP client

Protocols

Management protocolsSMI v1, SNMP, Telnet, SMI v2, TFTP, IP, ICMP, TCP, BOOTP, DHCP
Supported network protocolsIGMPv2, GARP, GVRP, GMP, IPv6

Design

Rack mountingYes
StackableYes
Form factor1U
Product colourBlack

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Other features

Dell E-Value CodeIN TAB

Operational conditions

Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)10 - 90%

Weight & dimensions

Width330 mm
Depth230.5 mm
Height42 mm
Weight3.04 kg
