GO-SW-24G Unmanaged L2 Gigabit Ethernet (10/100/1000) 1U Black
Model GO-SW-24GEAN 5054531017001
69 specifications
- Type1U
- Weight1.35 kg
- ColourBlack
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity24
- 10G supportNo
Overview
- Type
- 1U
- Weight
- 1.35 kg
- Colour
- Black
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 24
- 10G support
- No
- Brand
- D-Link
- Category
- Network Switch
- Model
- GO-SW-24G
- Part numbers
- GO-SW-24G, GO-SW-24G/E
- EAN / UPC
- 5054531017001, 790069396625, 4052305965467, 5425656676686 +1 more
- Also known as
- D-Link GO-SW-24G Unmanaged L2 Gigabit Ethernet (10/100/1000) 1U Black
Specifications
69 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-TX, 10BASE-T |
| Full duplex | Yes |
| Half duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
| Switching capacity | 48 Gbit/s |
| Forwarding rate | 35.71 Mpps |
| Store-and-forward | Yes |
| Number of queues | 8 |
| Jumbo frames support | Yes |
| Jumbo frames | 9216 |
| Packet buffer memory | 0.512 MB |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
| Number of fans | 0 fan(s) |
Performance
| Specification | Value |
|---|---|
| Mean time between failures (MTBF) | 302287 h |
Power
| Specification | Value |
|---|---|
| Power supply included | Yes |
| Redundant power supply (RPS) support | No |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 15.4 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Heat dissipation | 52.54 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 280 mm |
| Depth | 180 mm |
| Height | 44 mm |
| Weight | 1.35 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 245 mm |
| Package depth | 438 mm |
| Package height | 77 mm |
| Package weight | 2.3 kg |
Technical details
| Specification | Value |
|---|---|
| Master (outer) cases per pallet (air) | 28 pc(s) |
| Master (outer) cases per pallet (sea) | 28 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross weight (air) | 373.6 kg |
| Pallet gross weight (sea) | 373.6 kg |
| Pallet gross width | 120 cm |
| Pallet height (air) | 2.02 m |
| Pallet height (sea) | 2.02 m |
| Products per pallet (air) | 140 pc(s) |
| Products per pallet (sea) | 140 pc(s) |
| Products per shipping (inner) case | 5 pc(s) |
| Shipping (inner) case gross weight | 12.4 kg |
| Shipping (inner) case height | 27 cm |
| Shipping (inner) case length | 46.3 cm |
| Shipping (inner) case net weight | 11.5 kg |
| Shipping (inner) case width | 41.3 cm |
Certificates
| Specification | Value |
|---|---|
| Certification | CE Class A, FCC Class A, VCCI Class A, BSMI, CCC UL, CB, LVD, BSMI, CCC |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
