D-Link DXS-3600-16S Managed Gigabit Ethernet (10/100/1000) Black
Model DXS-3600-16SPart no. DXS-3600-16S/SIEAN 5054484739166
51 specifications
- Weight9.89 kg
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
- 10G supportYes
- MAC address table12800 entries
Overview
- Weight
- 9.89 kg
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- 10G support
- Yes
- MAC address table
- 12800 entries
- Brand
- D-Link
- Category
- Network Switch
- Model
- DXS-3600-16S
- Part number
- DXS-3600-16S/SI
- EAN / UPC
- 5054484739166, 790069382949, 790069384776, 7900693829496 +1 more
- Also known as
- D-Link DXS-3600-16S Managed Gigabit Ethernet (10/100/1000) Black
Specifications
51 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity | 8 |
| Console port | RJ-45 |
| Compatible memory cards | SD |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3 |
| 10G support | Yes |
| Port mirroring | Yes |
| Full duplex | Yes |
| Flow control support | Yes |
| Head-of-line (HOL) blocking | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 12800 entries |
| Switching capacity | 480 Gbit/s |
| Throughput | 357.14 Mpps |
| Number of queues | 8 |
| Jumbo frames support | Yes |
| Packet buffer memory | 9 MB |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP server, DHCP client |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| SSH/SSL support | Yes |
| Security algorithms | SSH |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Product colour | Black |
| LED indicators | Yes |
| Number of fans | 3 fan(s) |
| Safety | CB, cUL |
Performance
| Specification | Value |
|---|---|
| Firmware upgradeable | Yes |
Power
| Specification | Value |
|---|---|
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 69.9 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | 40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Heat dissipation | 253.36 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 440 mm |
| Depth | 506 mm |
| Height | 44 mm |
| Weight | 9.89 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC, CE, C-Tick, IC, VCCI, BSMI |
