DXS-1210-12SC/E network switch Managed L2
10G Ethernet (100/1000/10000) 1U Black, Silver
Model DXS-1210-12SC/EEAN 790069467646
56 specifications
- Type1U
- Weight2.73 kg
- ColourBlack, Silver
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity2
- 10G supportYes
Overview
- Type
- 1U
- Weight
- 2.73 kg
- Colour
- Black, Silver
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 2
- 10G support
- Yes
- Brand
- D-Link
- Category
- Network Switch
- Model
- DXS-1210-12SC/E
- Part number
- DXS-1210-12SC/E
- EAN / UPC
- 790069467646
- Also known as
- D-Link DXS-1210-12SC/E network switch Managed L2 10G Ethernet (100/1000/10000) 1U Black, Silver
Specifications
56 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
| MIB support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 2 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| SFP+ module slots quantity | 10 |
| Fiber optic connector | SFP+ |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z |
| 10G support | Yes |
| Cable types supported | Cat6, Cat6a, Cat7 |
| Auto MDI/MDI-X | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 16000 entries |
| Switching capacity | 240 Gbit/s |
| Throughput | 178.56 Mpps |
| Jumbo frames support | Yes |
Security
| Specification | Value |
|---|---|
| IGMP snooping | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black, Silver |
| LED indicators | Yes |
| Safety | cUL, CB, CE, CCC, BSMI |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 43.81 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 210 mm |
| Depth | 440 mm |
| Height | 44 mm |
| Weight | 2.73 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 349 mm |
| Package depth | 546 mm |
| Package height | 96 mm |
| Package weight | 3.91 kg |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Technical details
| Specification | Value |
|---|---|
| Master (outer) cases per pallet (air) | 18 pc(s) |
| Master (outer) cases per pallet (sea) | 30 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross weight (air) | 247.3 kg |
| Pallet gross weight (sea) | 399.6 kg |
| Pallet gross width | 120 cm |
| Pallet height (air) | 128.4 cm |
| Pallet height (sea) | 2.05 m |
| Products per pallet (air) | 54 pc(s) |
| Products per pallet (sea) | 90 pc(s) |
| Products per shipping (inner) case | 3 pc(s) |
| Shipping (inner) case gross weight | 12.7 kg |
| Shipping (inner) case height | 38.3 cm |
| Shipping (inner) case length | 56.2 cm |
| Shipping (inner) case net weight | 11.7 kg |
| Shipping (inner) case width | 31.4 cm |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
