D-Link DXS-1100-10TS network switch Managed L2
10G Ethernet (100/1000/10000) 1U Black
Model DXS-1100-10TSPart no. DXS-1100-10TS+DXE-820TEAN 112350192202
77 specifications
- Noise46.4 dB
- Type1U
- Weight2.69 kg
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity8
Overview
- Noise
- 46.4 dB
- Type
- 1U
- Weight
- 2.69 kg
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 8
- Brand
- D-Link
- Category
- Network Switch
- Model
- DXS-1100-10TS
- Part numbers
- DXS-1100-10TS+DXE-820T, DXS1100-10TS/DXE820T, DXS-1100-10TS+DEM-431XT, DXS-1100-10TS/KIT2, DXS-1100-10TS, DXS-1100-10TS/KIT
- EAN / UPC
- 112350192202, 790069422836, 5057103098330
- Also known as
- D-Link DXS-1100-10TS network switch Managed L2 10G Ethernet (100/1000/10000) 1U Black
Specifications
77 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
| ARP inspection | Yes |
| System event log | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| SFP+ module slots quantity | 2 |
| Fiber optic connector | SFP+ |
| USB 2.0 ports quantity | 0 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1D, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z |
| 10G support | Yes |
| Copper ethernet cabling technology | 10GBASE-T |
| Port mirroring | Yes |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Broadcast storm control | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Virtual LAN features | Port-based VLAN |
| Number of VLANs | 128 |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 16000 entries |
| Switching capacity | 200 Gbit/s |
| Throughput | 148.81 Mpps |
| Store-and-forward | Yes |
| Number of queues | 8 |
| Jumbo frames support | Yes |
| Jumbo frames | 9216 |
Security
| Specification | Value |
|---|---|
| IGMP snooping | Yes |
| Queue scheduling algorithms | SPQ, Weighted Round Robin (WRR) |
| SSH/SSL support | Yes |
| Security algorithms | SNMP |
| Static port security | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
| Number of fans | 2 fan(s) |
Performance
| Specification | Value |
|---|---|
| Flash memory | 128 MB |
| Noise level | 46.4 dB |
| Mean time between failures (MTBF) | 585.959 h |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 50.9 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Heat dissipation | 173.57 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 441 mm |
| Depth | 210 mm |
| Height | 44 mm |
| Weight | 2.69 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 348 mm |
| Package depth | 511 mm |
| Package height | 91 mm |
| Package weight | 4.14 kg |
Technical details
| Specification | Value |
|---|---|
| Master (outer) cases per pallet (air) | 40 pc(s) |
| Master (outer) cases per pallet (sea) | 40 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross weight (air) | 552.4 kg |
| Pallet gross weight (sea) | 552.4 kg |
| Pallet gross width | 120 cm |
| Pallet height (air) | 2.05 m |
| Pallet height (sea) | 2.05 m |
| Products per pallet (air) | 120 pc(s) |
| Products per pallet (sea) | 120 pc(s) |
| Products per shipping (inner) case | 3 pc(s) |
| Shipping (inner) case gross weight | 13.3 kg |
| Shipping (inner) case height | 38.3 cm |
| Shipping (inner) case length | 52.9 cm |
| Shipping (inner) case net weight | 9.67 kg |
| Shipping (inner) case width | 29.6 cm |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
