DSS-100E-9P network switch Unmanaged Fast Ethernet (10/100) Power over Ethernet (PoE) Black
Model DSS-100E-9PEAN 790069451089
39 specifications
- Noise0 dB
- Weight410 g
- ColourBlack
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity8
- 10G supportNo
Overview
- Noise
- 0 dB
- Weight
- 410 g
- Colour
- Black
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 8
- 10G support
- No
- Brand
- D-Link
- Category
- Network Switch
- Model
- DSS-100E-9P
- Part number
- DSS-100E-9P
- EAN / UPC
- 790069451089
- Also known as
- D-Link DSS-100E-9P network switch Unmanaged Fast Ethernet (10/100) Power over Ethernet (PoE) Black
Specifications
39 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Gigabit Ethernet (copper) ports quantity | 1 |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Auto MDI/MDI-X | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 2000 entries |
| Switching capacity | 1.8 Gbit/s |
| Forwarding rate | 2.67 Mpps |
| Store-and-forward | Yes |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet forwarding rate (100 Mbps) | 148800 pps |
| Packet buffer memory | 0.128 MB |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black |
| LED indicators | Activity, Link, PoE, Power, Speed |
Performance
| Specification | Value |
|---|---|
| Noise level | 0 dB |
| Mean time between failures (MTBF) | 52308 h |
Power
| Specification | Value |
|---|---|
| Power supply included | Yes |
| Power consumption (max) | 102 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 92 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Heat dissipation | 486.7 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 177 mm |
| Depth | 104 mm |
| Height | 26 mm |
| Weight | 410 g |
Packaging content
| Specification | Value |
|---|---|
| User guide | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
