6-port Multi-Gigabit Unmanaged Switch
Model DMS-106XTEAN 790069459818
41 specifications
- Weight680 g
- ColourGrey
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity6
- 10G supportYes
- MAC address table4000 entries
Overview
- Weight
- 680 g
- Colour
- Grey
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 6
- 10G support
- Yes
- MAC address table
- 4000 entries
- Brand
- D-Link
- Category
- Network Switch
- Model
- DMS-106XT
- Part number
- DMS-106XT
- EAN / UPC
- 790069459818
- Also known as
- D-Link 6-port Multi-Gigabit Unmanaged Switch
Specifications
41 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 6 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| 2.5G Ethernet (copper) ports quantity | 5 |
| 10G Ethernet (copper) ports quantity | 1 |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
| 10G support | Yes |
| Copper ethernet cabling technology | 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 4000 entries |
| Switching capacity | 45 Gbit/s |
| Store-and-forward | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Stackable | No |
| Product colour | Grey |
| Housing material | Aluminium |
| LED indicators | Activity, Link, Power |
Performance
| Specification | Value |
|---|---|
| Fanless | Yes |
| Mean time between failures (MTBF) | 489941 h |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| DC input voltage | 12 V |
| Input current | 1.5 A |
| Power consumption (max) | 10.6 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Heat dissipation | 36.17 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 217 mm |
| Depth | 163 mm |
| Height | 33 mm |
| Weight | 680 g |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
| Certification | FCC, RCM, BSMI, VCCI |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
