D-Link 8-Port L2 Managed Switch with

6 x 10/100/1000BaseT(X) (4 PoE) & 2 x 100/1000BaseSFP

Model DIS‑300G‑8PSWPart no. DIS-300G-8PSWEAN 790069437939

80 specifications

Weight1.31 kg
ColourBlack
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity6
10G supportNo
MAC address table8000 entries

See all specifications

Overview

Weight: 1.31 kg
Colour: Black
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 6
10G support: No
MAC address table: 8000 entries

Brand: D-Link
Category: Network Switch
Model: DIS‑300G‑8PSW
Part number: DIS-300G-8PSW
EAN / UPC: 790069437939
Also known as: D-Link 8-Port L2 Managed Switch with 6 x 10/100/1000BaseT(X) (4 PoE) & 2 x 100/1000BaseSFP

Specifications

80 specifications in 16 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes
Traffic shaping	Yes
System event log	Yes
MIB support	RFC 1757 RMON 1,2,3,9; RFC 2674 Q MIB RFC‑1213 MIB‑II; RFC‑1493 MIB; RFC 2233 IF MIB

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	6
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP module slots quantity	2
Fiber optic connector	LC

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
10G support	No
Full duplex	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Broadcast storm control	Yes
Flow control support	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Tagged VLAN, Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN, IP subnet–based VLAN
Number of VLANs	1024

Data transmission

Specification	Value
MAC address table	8000 entries
Store-and-forward	Yes
Jumbo frames support	Yes
Jumbo frames	9000

Security

Specification	Value
DHCP features	DHCP server, DHCP snooping, DHCP relay, DHCP client
Authentication type	IEEE 802.1x, RADIUS
Queue scheduling algorithms	SPQ, Weighted Round Robin (WRR)
Security algorithms	HTTPS, SNMP, SNMPv3, SSH

Multicast features

Specification	Value
Multicast support	Yes

Design

Specification	Value
Rack mounting	No
Product colour	Black
LED indicators	Alarm, LAN, PoE, Power
DIN rail mounting	Yes
International Protection (IP) code	IP30
Wall mountable	Yes
Electromagnetic compatibility	FCC 15, EN 61000‑6‑2, EN 61000‑6‑4, EN 61000‑4‑2, ‑3, ‑4, ‑5, ‑6

Performance

Specification	Value
Firmware upgradeable	Yes

Power

Specification	Value
DC input voltage	48 - 58 V
Power consumption (typical)	14 W
Power consumption (max)	265 W
Power protection features	Over current, Reverse polarity

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	4
Power over Ethernet (PoE) voltage range	54 - 58 V
Power over Ethernet (PoE) power per port	60 W
Total Power over Ethernet (PoE) budget	120 W

Operational conditions

Specification	Value
Operating temperature (T-T)	-40 - 75 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95%

Weight & dimensions

Specification	Value
Width	71 mm
Depth	154 mm
Height	128 mm
Weight	1.31 kg

Packaging data

Specification	Value
Package width	195 mm
Package depth	242 mm
Package height	138 mm
Package weight	1.81 kg

Technical details

Specification	Value
Master (outer) cases per pallet (air)	20 pc(s)
Master (outer) cases per pallet (sea)	28 pc(s)
Pallet gross length	120 cm
Pallet gross weight (air)	404.4 kg
Pallet gross weight (sea)	559.4 kg
Pallet gross width	110 cm
Pallet height (air)	148.5 cm
Pallet height (sea)	2.02 m
Products per pallet (air)	200 pc(s)
Products per pallet (sea)	280 pc(s)
Products per shipping (inner) case	10 pc(s)
Shipping (inner) case gross weight	19.4 kg
Shipping (inner) case height	27 cm
Shipping (inner) case length	69.5 cm
Shipping (inner) case net weight	18.1 kg
Shipping (inner) case width	40.5 cm

Certificates

Specification	Value
Certification	IEC60068‑2‑6, IEC60068‑2‑27, IEC60068‑2‑32, UL 60950‑1, CE, FCC, RoHS, WEEE

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
