1000) Black

Model DIS-200G-12SWEAN 790069433528

64 specifications

Overview

Brand: D-Link
Category: Network Switch
Model: DIS-200G-12SW
Part number: DIS-200G-12SW
EAN / UPC: 790069433528
Also known as: D-Link DIS-200G-12SW network switch Managed L2 Gigabit Ethernet (10/100/1000) Black

64 specifications in 14 groups

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes
Configuring Location Settings (CLI)	Yes
System event log	Yes

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	10
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	10
Installed SFP modules quantity	2
Installed SFP+ modules quantity	0
Console port	RJ-45

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring	Yes
Full duplex	Yes
Active link detection	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Broadcast storm control	Yes
Flow control support	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Port-based VLAN, Tagged VLAN, Voice VLAN
Number of VLANs	4094

Specification	Value
DHCP features	DHCP client
IGMP snooping	Yes
Authentication	Port-based authentication
Authentication type	RADIUS
Queue scheduling algorithms	SPQ, Weighted Round Robin (WRR)
Security algorithms	802.1x RADIUS, SSL/TLS

Specification	Value
Multicast support	Yes

Specification	Value
Management protocols	SNMP v1/v2c/v3, SNTP, Telnet

Specification	Value
Rack mounting	Yes
Stackable	No
Product colour	Black
Housing material	Metal
LED indicators	Yes
DIN rail mounting	Yes
International Protection (IP) code	IP30
Wall mountable	No

Specification	Value
Mean time between failures (MTBF)	219314 h

Specification	Value
Power over Ethernet (PoE)	No

Specification	Value
Operating temperature (T-T)	-40 - 75 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Heat dissipation	35.01 BTU/h

Specification	Value
Certification	CE, FCC, BSMI EN 61000-4-2 ESD EN 61000-4-3 RS EN 61000-4-4 EFT EN 61000-4-5 EN 61000-4-6 CS EN 61000-4-8 IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6
