1000) Power over Ethernet (PoE) Black

Model DIS-200G-12PSWEAN 790069433511

67 specifications

Weight1.76 kg
ColourBlack
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity10
10G supportNo
Fiber ethernet cabling technology1000BASE-X

See all specifications

Overview

Weight: 1.76 kg
Colour: Black
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 10
10G support: No
Fiber ethernet cabling technology: 1000BASE-X

Brand: D-Link
Category: Network Switch
Model: DIS-200G-12PSW
Part number: DIS-200G-12PSW
EAN / UPC: 790069433511
Also known as: D-Link DIS-200G-12PSW network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Specifications

67 specifications in 15 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes
Configuring Location Settings (CLI)	Yes
System event log	Yes

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	10
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	10
Installed SFP modules quantity	2
Installed SFP+ modules quantity	0
Console port	RJ-45

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring	Yes
Full duplex	Yes
Active link detection	Yes
Auto MDI/MDI-X	Yes
Broadcast storm control	Yes
Flow control support	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Port-based VLAN, Tagged VLAN, Voice VLAN

Optical fiber

Specification	Value
Fiber ethernet cabling technology	1000BASE-X

Data transmission

Specification	Value
MAC address table	8000 entries
Switching capacity	24 Gbit/s
Forwarding rate	17.856 Mpps
Store-and-forward	Yes
Jumbo frames support	Yes
Jumbo frames	9600

Security

Specification	Value
DHCP features	DHCP client
IGMP snooping	Yes
Authentication	Port-based authentication
Authentication type	RADIUS
Queue scheduling algorithms	SPQ, Weighted Round Robin (WRR)
Security algorithms	802.1x RADIUS, SSL/TLS

Multicast features

Specification	Value
Multicast support	Yes

Protocols

Specification	Value
Management protocols	SNMP v1/v2c/v3, SNTP, Telnet

Design

Specification	Value
Rack mounting	Yes
Stackable	No
Product colour	Black
Housing material	Metal
LED indicators	Yes
DIN rail mounting	Yes
International Protection (IP) code	IP30
Wall mountable	Yes

Performance

Specification	Value
Mean time between failures (MTBF)	156452 h

Power

Specification	Value
Power source	PoE
DC input voltage	46 - 54 V
Power consumption (typical)	7.02 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	8
Power over Ethernet (PoE) voltage	260 V
Total Power over Ethernet (PoE) budget	240 W

Operational conditions

Specification	Value
Operating temperature (T-T)	-40 - 75 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 2000 m
Heat dissipation	887.16 BTU/h

Weight & dimensions

Specification	Value
Width	171.2 mm
Depth	53 mm
Height	210 mm
Weight	1.76 kg

Certificates

Specification	Value
Certification	CE, FCC, BSMI EN 61000-4-2 ESD EN 61000-4-3 RS EN 61000-4-4 EFT EN 61000-4-5 EN 61000-4-6 CS EN 61000-4-8 IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6
